DS1921L-F5X Datasheet

IC型號：
DS1921L-F5X
PDF描述：
Thermochron iButton
文件大小：
377.93KB
PDF頁數：
40頁
芯片廠家：
ETC

閱覽下載糾錯 0

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DS1921L-F5X

Thermochron iButton

www.maxim-ic.com

SPECIAL FEATURES*

摟

Digital thermometer measures temperature in

0.5擄C increments (accuracy 鹵1.0擄C)

Built-in real-time clock (RTC) and timer has

accuracy of

鹵2

minutes per month from 0擄C

to 45擄C

Automatically wakes up and measures tem-

perature at user-programmable intervals from

1 to 255 minutes

Logs up to 2048 consecutive temperature

measurements in protected nonvolatile (NV)

memory

Records a long-term temperature histogram

with 2.0擄C resolution

Programmable temperature-high and tem-

perature-low alarm trip points

Records up to 24 time stamps and durations

when temperature leaves the range specified

by the trip points

512 bytes of general-purpose read/write NV

memory

Typical lifetime more than 9 years

Communicates to host with a single digital

signal at 14.1kbits or 125kbits per second

using 1-Wire

廬

protocol

摟

Durable stainless steel case engraved with

registration number withstands harsh envi-

ronments

Easily affixed with self-stick adhesive back-

ing, latched by its flange, or locked with a

ring pressed onto its rim

Presence detector acknowledges when reader

first applies voltage

Meets UL#913 (4th Edit.). Intrinsically Safe

Apparatus: approved under Entity Concept

for use in Class I, Division 1, Group A, B, C

and D Locations (application pending)

F5 MICROCAN

5.89

0.36

0.51

漏 1993

16.25

YYWW REGISTERED

17.35

15C000FBC52B

GND

All dimensions are shown in millimeters.
