www.maxim-ic.com
DS1816
3.3V EconoReset with
Open Drain Output
PIN ASSIGNMENT
3
FEATURES
摟
摟
摟
摟
摟
摟
摟
摟
摟
Automatically restarts a microprocessor after
power failure
Maintains reset for 150ms after V
CC
returns to
an in-tolerance condition
Reduces need for discrete components
Precision temperature-compensated voltage
reference and voltage sensor
Accurate 5%, 10% or 20% power monitoring
20% tolerance for use with 3V systems
Low-cost TO-92 or space saving SOT-23
packages available
Efficient open-drain output with internal
5kW pull-up resistor
Operating temperature -40擄C to +85擄C
1
2
SOT-23 PACKAGE
1 2 3
1 2 3
TO-92 PACKAGE
See Mech.
Drawings Section
PIN DESCRIPTION
TO-92
1
2
3
RST
V
CC
GND
Active Low Reset Output
Power Supply
Ground
SOT-23
1
2
3
RST
V
CC
GND
Active Low Reset Output
Power Supply
Ground
DESCRIPTION
The DS1816 EconoReset uses a precision temperature reference and comparator circuit to monitor the
status of the power supply (V
CC
). When an out-of-tolerance condition is detected, an internal power-fail
signal is generated which forces reset to the active state. When V
CC
returns to an in-tolerance condition,
the reset signal is kept in the active state for approximately 150ms to allow the power supply and
processor to stabilize.
1 of 5
101601
