DS1703K

Operating Instructions

www.maxim-ic.com

INTRODUCTION

The DS1703K is a software evaluation kit designed for use with the Dallas Semiconductor family of

3-wire temperature sensing devices. Full device functionality is supported for the DS1620, DS1720,

DS1626, DS1726, and DS1722. The SPI interface of the DS1722 is also supported. All user registers

can be accessed through the software, allowing full read/write control of the devices. Both

Fahrenheit and Celsius temperature readouts are provided for ease of use.

The software was designed for Windows

operating systems, and has been tested on Windows 98,

Windows 2000, and Windows NT operating systems.

STARTING THE DS1703K EVALUATION KIT

The first step required to run the DS1703K evaluation software is to connect the DS9123 to an

available serial port on the desired computer. The DS9123 is the serial interface brick that translates

the serial data to the 3-Wire interface. With the DS9123 connected, the user can run the

DS1703K.exe executable. The evaluation board does not need to be present to run the software. The

first screen displayed is shown in Figure 1.

Figure 1. DS1703K Splash Screen

If the DS9123 module is not present, the software will not load completely and the message box

shown in Figure 2 appears. If this message appears, there is a problem communicating with the

DS9123, and the connection should be verified.

Figure 2. Unable to Initialize Screen
