DS1702K Datasheet

  • DS1702K

  • 2-Wire Thermal Device Evaluation Kit

  • 16頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DS1702K 2-Wire Thermal Device
Evaluation Kit
Kit Instructions and Operating Procedures
www.maxim-ic.com
F
EATURES
:
路
Full-Featured Evaluation Kit for the DS1702K includes
testing software for the
DS1621, DS1721, DS1624,
DS1629, DS75, and DS1775
devices. The DS1702K
is comprised of five separate and unique software kits:
the DS1721K.exe (works for both the DS1621 and
DS1721), DS1624K.exe, DS1629K.exe, and the
DS75K.exe. Each software package works through the
same 2-wire DS1702K board (included in the
DS1702K kit) with jumper selections.
The DS75K is
completely software compatible with the DS1775
device requirements. However, the SOT23-5 (5-pin
socket) is not provided.
Compatible with
Windows
TM
95,
Windows
98, and
Windows
NT Operating Systems.
Complete read/write access to all registers within the
DS1621, DS1721, DS1624, DS1629, and DS75
devices.
Measures temperatures from the full range of the
devices -55擄C to +125擄C. Fahrenheit equivalent is
-67擄F to +257擄F.
Celsius and Fahrenheit temperature reading and
charting is provided for the DS75, DS1621, and
DS1721 devices.
H
ARDWARE
:
The 2-wire board as shown in Figure 1.0 allows the user to
test the functional capabilities of each device. The circuitry
allows the user to read the temperature, and to read and
write the appropriate registers of the socketed device.
Figure 1.0 2-Wire Board Block Diagram
路
路
路
路
COM P
ORT
S
ELECTIONS
The serial port selection can be changed by the user at
any time by changing the 鈥淐omm Port鈥?number on the
鈥淪elect Preferences鈥?form (see Figure 2.0). The 鈥淪elect
Preferences鈥?form resides under the 鈥淧references鈥?menu.
The baud rate selection also resides on the 鈥淪elect
Preferences鈥?form.
Figure 2.0 COM Port Preferences
K
IT
C
ONTENTS
:
1. Separate Programming Software on the CDROM
containing the DS1721K.exe, DS1624K.exe, DS1629K.exe
and the DS75K.exe 鈥淪etup.exe鈥?Installers.
2. 87-1702K-000, 2-Wire Demo board.
3. Demo Kit Documentation Provided on CDROM for
each software program.
4. DS9123
Universal Brick
serial port device and cable.
To use the kit, you will also need:
1. An available Serial Port to connect the DS9123
Universal Brick
modular data cable.
2. Finally, you will need to provide a +2.7V to +5V
regulated power supply with banana-jack leads.
Windows is a trademark of Microsoft.
1 of 16
