DRV102F/500 Datasheet

  • DRV102F/500

  • PWM SOLENOID/VALVE DRIVER

  • 23頁

  • TI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DRV
102
DRV
102
DRV102
SBVS009A 鈥?JANUARY 1998 鈥?REVISED OCTOBER 2003
PWM SOLENOID/VALVE DRIVER
FEATURES
q
HIGH OUTPUT DRIVE: 2.7A
q
WIDE SUPPLY RANGE: +8V to +60V
q
COMPLETE FUNCTION
PWM Output
Internal 24kHz Oscillator
Digital Control Input
Adjustable Delay and Duty Cycle
Over/Under Current Indicator
q
FULLY PROTECTED
Thermal Shutdown with Indicator
Internal Current Limit
q
POWER PACKAGES: 7-Lead TO-220 and
7-Lead Surface-Mount DDPAK
APPLICATIONS
q
ELECTROMECHANICAL DRIVER:
Solenoids
Positioners
Actuators
High Power Relays/Contactors
Valves
Clutches/Brakes
q
SOLENOID OVERHEAT PROTECTORS
q
FLUID AND GAS FLOW CONTROLLERS
q
PART HANDLERS
q
ELECTRICAL HEATERS/COOLERS
q
MOTOR SPEED CONTROLLERS
q
INDUSTRIAL CONTROL
q
FACTORY AUTOMATION
q
MEDICAL ANALYSIS
q
PHOTOGRAPHIC PROCESSING
The DRV102 can be set to provide a strong initial closure,
automatically switching to a 鈥渟oft鈥?hold mode for power
savings. Duty cycle can be controlled by a resistor, analog
voltage, or digital-to-analog converter for versatility. A flag
output indicates thermal shutdown and over/under current
limit. A wide supply range allows use with a variety of
actuators.
The DRV102 is available in 7-lead staggered TO-220 pack-
age and a 7-lead surface-mount DDPAK plastic power
package. It operates from 鈥?5擄C to +125擄C.
Flag
7
DRV102
Thermal Shutdown
Over/Under Current
24kHz
Oscillator
Input
1
PWM
Delay
2
Delay
Adjust
3
Gnd
(1)
4
6
Out
Load
5
V
S
DESCRIPTION
The DRV102 is a high-side power switch employing a
pulse-width modulated (PWM) output. Its rugged design is
optimized for driving electromechanical devices such as
valves, solenoids, relays, actuators, and positioners. The
DRV102 is also ideal for driving thermal devices such as
heaters and lamps. PWM operation conserves power and
reduces heat rise in the device, resulting in higher reliability.
In addition, adjustable PWM allows fine control of the
power delivered to the load. Time from dc output to PWM
output is externally adjustable.
(+8V to +60V)
On (TTL-Compatible)
Off
Duty Cycle
Adjust
(Gnd electrically
connected to tab)
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
All trademarks are the property of their respective owners.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
Copyright 漏 1998-2003, Texas Instruments Incorporated
www.ti.com
