Designed for Short-Range Wireless Data Communications
Supports up to 19.2 kbps Encoded Data Transmissions
3 V, Low Current Operation plus Sleep Mode
Ready to Use OEM Module
The DR5001 receiver module is ideal for short-range wireless data applications where robust operation,
small size and low power consumption are required. The DR5001 utilizes RFM鈥檚 RX6001 amplifier-
sequenced hybrid (ASH) architecture to achieve this unique blend of characteristics. The receiver RX6001 is
sensitive and stable. A wide dynamic range log detector provides robust performance in the presence of on-
channel interference or noise. Two stages of SAW filtering provide excellent receiver out-of -band rejection.
The DR5001 includes the RX6001 plus all configuration components in a ready-to-use PCB assembly excel-
lent for prototyping and intermediate volume production runs.
Absolute Maximum Ratings
Rating
Power Supply and All Input/Output Pins
Non-Operating Case Temperature
Soldering Temperature (10 seconds)
Value
-0.3 to +4.0
-50 to +100
230
Units
V
擄C
擄C
Electrical Characteristics, 2.4 kbps On-Off Keyed
Characteristic
Operating Frequency
Modulation Type
Data Rate
Receiver Performance (OOK @ 2.4 kbps)
Input Current, 3 Vdc Supply
Input Signal for 10
-4
Rejection, 鹵30 MHz
Sleep Mode Current
Power Supply Voltage Range
Operating Ambient Temperature
BER, 25 C
R
REJ
t
SR
I
S
V
CC
T
A
2.7
-20
3
55
200
5
3.5
+65
I
R
-100
1.8
mA
dBm
dB
碌s
碌A
Vdc
擄C
Sym
f
O
Notes
Minimum
868.15
OOK
2.4
19.2
kbps
Typical
Maximum
868.55
Units
MHz
Sleep to Receive Switch Time(100 ms sleep, -85 dBm signal)
DR5001 Pin Out
RF
GND
14
AGC/VCC
PK DET
RX BBO
RX DATA
NC
1
2
3
4
5
6
GND
7
GND
DR5000 Pin Out
RFIO
13
12
11
10
9
8
CTR0
DR5001 Outline Drawing
DR5000 Outline Drawing
.70
.25
.20
.165
.10
CTR1
GND
VCC
LPF ADJ
.70
Dimensions in inches
