Designed for Short-Range Wireless Data Communications
Supports up to 115.2 kbps Encoded Data Transmissions
3 V, Low Current Operation plus Sleep Mode
Ready to Use OEM Module
The DR4101 transmitter module is ideal for short-range wireless data applications where robust operation,
small size and low power consumption are required. The DR4101 utilizes RFM鈥檚 TX5001 amplifier-
sequenced hybrid (ASH) architecture to achieve this unique blend of characteristics. The transmitter includes
provisions for on-off keyed (OOK) and ASK modulation. The transmitter employs SAW filtering to suppress
output harmonics, facilitating compliance with FCC 15.249 and similar regulations. The DR4101 includes the
TX5001 plus all configuration components in a ready-to-use PCB assembly, excellent for prototyping and
intermediate volume production runs.
315.00 MHz
Transmitter
Module
Absolute Maximum Ratings
Rating
Power Supply and All Input/Output Pins
Non-Operating Case Temperature
Soldering Temperature (10 seconds)
Value
-0.3 to +4.0
-50 to +100
230
Units
V
擄C
擄C
Electrical Characteristics, 2.4 kbps On-Off Keyed
Characteristic
Operating Frequency
Data Rate
OOK
ASK
Transmitter Performance (OOK @ 2.4 kbps)
Peak Input Current, 3 Vdc Supply
Peak Output Power
Turn On/Turn Off Time
Power Supply Voltage Range
Operating Ambient Temperature
I
TP
P
O
t
ON
/t
OFF
V
CC
T
A
2.7
-20
0.75
12/6
3.5
+65
12
mA
mW
碌s
Vdc
擄C
Sym
f
O
Notes
Minimum
314.8
Typical
Maximum
315.2
19.2
115.2
Units
MHz
kbps
DR4101 Pin Out
DR4101 Pin Out
RF
GND
14
VCC
NC
NC
NC
TX IN
1
2
3
4
5
6
GND
7
GND
RFIO
13
12
11
10
9
8
CTR0
CTR1
GND
DR4101 Outline Drawing
.30
.80
.20
.165
.10
.70
VCC
NC
RF Monolithics, Inc.
Phone: (972) 233-2903
Fax: (972) 387-8148
RFM Europe
Phone: 44 1963 251383
Fax: 44 1963 251510
漏1999 by RF Monolithics, Inc. The stylized RFM logo are registered trademarks of RF Monolithics, Inc.
E-mail: info@rfm.com
http://www.rfm.com
DR4101-121001
Page 1 of 2
