Designed for Short-Range Wireless Data Communications
Supports 1 Mbps Encoded Data Transmissions
3 V, Low Current Operation plus Sleep Mode
Ready to Use OEM Module
The DR3300 transceiver module is ideal for short-range wireless data applications where robust operation,
small size and low power consumption are required. The DR3300 utilizes RFM鈥檚 TR1100 amplifier-
sequenced hybrid (ASH) architecture to achieve this unique blend of characteristics. The receiver section of
the TR1100 is sensitive and stable. A wide dynamic range log detector provides robust performance in the
presence of on-channel interference or noise. Two stages of SAW filtering provide excellent receiver out-of-
band rejection. The TR1100 transmitter is optimized amplitude-shift keyed (ASK) modulation at data rates up
to 1 Mbps. The transmitter employs SAW filtering to suppress output harmonics, facilitating compliance with
FCC 15.249 and similar regulations. The DR3300 includes the TR1100 plus most configuration components
in a ready-to-use PCB assembly, excellent for prototyping and intermediate volume production runs.
Absolute Maximum Ratings
Rating
Power Supply and All Input/Output Pins
Non-Operating Case Temperature
Soldering Temperature (10 seconds)
Value
-0.3 to +4.0
-50 to +100
230
Units
V
擄C
擄C
Electrical Characteristics, 115.2 kbps Amplitude-Shift Keyed
Characteristic
Operating Frequency
Modulation Type
Data Rate
Receiver Performance (ASK @ 1 Mbps)
Input Current, 3 Vdc Supply
Input Signal for 10
-4
BER, 25 擄C
Rejection, 鹵30 MHz
Transmitter Performance (ASK @ 1 Mbps)
Peak Input Current, 3 Vdc Supply
Peak Output Power
Turn On/Turn Off Time
Sleep to Receive Switch Time (15 ms sleep, -70 dBm signal)
Sleep Mode Current
Transmit to Receive Switch Time (15 ms transmit, -70 dBm signal)
Receive to Transmit Switch Time
Power Supply Voltage Range
Operating Ambient Temperature
I
TP
P
O
t
ON
/t
OFF
t
SR
I
S
t
TOR
t
RTO
Vcc
T
A
2.7
-40
10
0.75
10
12
3.5
+85
0.75
0.2/0.2
12
mA
mW
碌s
碌s
碌A(chǔ)
碌s
碌s
Vdc
擄C
I
R
-76
R
REJ
55
4.8
mA
dBm
dB
1
Sym
f
O
Notes
Minimum
916.25
Typical
ASK
Mbps
Maximum
916.75
Units
MHz
RF Monolithics, Inc.
Phone: (972) 233-2903
Fax: (972) 387-8148
RFM Europe
Phone: 44 1963 251383
Fax: 44 1963 251510
漏1999 by RF Monolithics, Inc. The stylized RFM logo are registered trademarks of RF Monolithics, Inc.
E-mail: info@rfm.com
http://www.rfm.com
DR3300-060304
