Hall ICs
DN8797SE
3 V Hall IC
One-way magnetic field operation
Unit: mm
I
Overview
The DN8797SE is a 3 V operation Hall IC which
includes a Hall element, amplifier circuit, Schmidt circuit,
stabilized power supply and temperature compensation cir-
cuit which are integrated on a single chip with a fine pat-
terning technology. The magnetic input signal is output-
ted by being converted to high or low. We have improved
the conventional circuit to realize a stable operation cov-
ering from low to high supply voltage and from low to
high temperature.
4.52鹵0.3
4.52鹵0.3
(1.0)
2擄
45擄
(1.0)
0.55鹵0.15
12.5鹵06.5
(0.72)
0.4鹵0.1
1.27
2擄 to 5擄
123
(0.4)
1.54鹵0.1
I
Features
鈥?/div>
Wide operating supply voltage range
(V
CC
=
2.7 V to 16.0 V)
鈥?/div>
Wide operating ambient temperature (鈭?0擄C to
+85擄C)
鈥?/div>
Package: SIP 3-pins
鈥?/div>
Equipped with an output pull-up resistor (typical 56 k鈩?
2擄
R0.25
SSIP003-P-0000C
I
Applications
鈥?/div>
DC brushless motor, fan motor, rotation sensor, detec-
tion of cover open/close (example for a cellular phone),
position sensor
1
V
CC
I
Block Diagram
Constant
voltage source
56 k鈩?/div>
(typ.)
Comparator
Hall element
Amplifier
3
Out
GND
2
1
