Part Number:

www.SunLED.com

DMR20C-1

20.32mm (0.8鈥? SINGLE DIGIT NUMERIC DISPLAY

Features

0.8 INCH DIGIT HEIGHT.

LOW CURRENT OPERATION.

EXCELLENT CHARACTER APPEARANCE.

HIGH LIGHT OUTPUT.

EASY MOUNTING ON P.C. BOARDS OR SOCKETS.

I.C. COMPATIBLE.

MECHANICALLY RUGGED.

STANDARD : GRAY FACE, WHITE SEGMENT.

RoHS COMPLIANT.

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is 鹵 0.25(0.01") unless otherwise noted.

3.Specifications are subject to change without notice.

Operating Characteristics

(T

A

=25擄C)

Forward Voltage (Typ.)

(I

F

=10mA)

Unit

V

mA

mA

mW

擄C

Forward Voltage (Max.)

(I

F

=10mA)

Reverse Current (Max.)

(V

R

=5V)

Wavelength Of Peak

Emission (Typ.)

(I

F

=10mA)

Wavelength Of Dominant

Emission (Typ.)

(I

F

=10mA)

Spectral Line Full Width

At Half-Maximum (Typ.)

(I

F

=10mA)

Capacitance (Typ.)

(V

F

=0V, f=1MHz)

V

F

V

F

I

R

MR

(GaAlAs)

1.8

2.5

10

Unit

V

V

uA

Absolute Maximum Ratings

(T

A

=25擄C)

Reverse Voltage

Forward Current

Forward Current (Peak)

1/10 Duty Cycle

0.1ms Pulse Width

Power Dissipation

Operating Temperature

Storage Temperature

Lead Solder Temperature

[2mm Below Package Base]

V

R

I

F

i

FS

P

T

T

A

Tstg

MR

(GaAlAs)

5

30

155

75

-40 ~ +85

-40 ~ +85

位

P

660

nm

位

D

640

nm

螖位

20

nm

260擄C For 3~5 Seconds

C

45

pF

Part

Number

Emitting

Color

Emitting

Material

Luminous

Intensity

(IF=10mA)

ucd

min.

typ.

35990

Wavelength

nm

位

P

Description

DMR20C-1

Red

GaAlAs

8000

660

Common Cathode, Rt. Hand Decimal

Published Date : MAR 01,2008

Drawing No : SDSA2111

V4

Checked : Shin Chi

P.1/4
