DMEG 250
250 Watts, 50 Volts, Pulsed
Avionics 960 - 1215 MHz
GENERAL DESCRIPTION
The DMEG 250 is a high power COMMON BASE bipolar transistor. It is
designed for pulsed systems in the frequency band 960-1215 MHz. The
device has gold thin-film metallization for proven highest MTTF. The
transistor includes input and output prematch for broadband capability. Low
thermal resistance package reduces junction temperature, extends life.
CASE OUTLINE
55AW, STYLE 1
ABSOLUTE MAXIMUM RATINGS
Maximum Power Dissipation @ 25
o
C
2
Maximum Voltage and Current
BVces Collector to Base Voltage
BVebo Emitter to Base Voltage
Ic
Collector Current
Maximum Temperatures
Storage Temperature
Operating Junction Temperature
875 Watts
55 Volts
4.0 Volts
30 Amps
- 65 to + 200
o
C
+ 200
o
C
ELECTRICAL CHARACTERISTICS @ 25
O
C
SYMBOL
Pout
Pin
Pg
畏
c
VSWR
BVebo
BVces
Cob
h
FE
2
CHARACTERISTICS
Power Out
Power Input
Power Gain
Collector Efficiency
Load Mismatch Tolerance
TEST CONDITIONS
F = 960-1215 MHz
Vcc = 50 Volts
PW = 10
碌sec
DF = 5%
F = 1090 MHz
Ie = 20 mA
Ic = 25 mA
Vcb = 50 Volts
Ic = 1 mA, Vce = 5 V
MIN
250
TYP
MAX
60
UNITS
Watts
Watts
dB
%
6.2
35
5:1
胃
jc
Emitter to Base Breakdown
Collector to Emitter Breakdown
Capacitance Collector to Base
DC - Current Gain
Thermal Resistance
4.0
55
10
0.2
Volts
Volts
pF
C/W
o
Note 1: At rated output power and pulse conditions
2: At rated pulse conditions
Issue A, July 1997
GHz TECHNOLOGY INC. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. GHz RECOMMENDS THAT BEFORE
THE PRODUCT(S) DESCRIBED HEREIN ARE WRITTEN INTO SPECIFICATIONS, OR USED IN CRITICAL APPLICATIONS, THAT THE
PERFORMANCE CHARACTERISTICS BE VERIFIED BY CONTACTING THE FACTORY.
GHz Technology Inc. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 / 986-8120
