DME 150
150 Watts, 50 Volts, Pulsed
Avionics 1025 - 1150 MHz
GENERAL DESCRIPTION
The DME 150 is a high power COMMON BASE bipolar transistor. It is
designed for pulsed systems in the frequency band 1025-1150 MHz. The
device has gold thin-film metallization and diffused ballasting for proven
highest MTTF. The transistor includes input and ouput prematch for
broadband capabilit. Low thermal resistance package reduces junction
temperature, extends life.
CASE OUTLINE
55AY, STYLE 1
ABSOLUTE MAXIMUM RATINGS
Maximum Power Dissipation @ 25
o
C
2
Maximum Voltage and Current
BVces
Collector to Base Voltage
BVebo Emitter to Base Voltage
Ic
Collector Current
Maximum Temperatures
Storage Temperature
Operating Junction Temperature
290 Watts
55 Volts
4.0 Volts
15 Amps
- 65 to + 150
o
C
+ 150
o
C
ELECTRICAL CHARACTERISTICS @ 25
O
C
SYMBOL
Pout
Pin
Pg
畏
c
VSWR
BVebo
BVces
Cob
h
FE
CHARACTERISTICS
Power Out
Power Input
Power Gain
Collector Efficiency
Load Mismatch Tolerance
Emitter to Base Breakdown
Collector to Emitter Breakdown
Capacitance Collector to Base
DC - Current Gain
Thermal Resistance
TEST CONDITIONS
F = 1025-1150 MHz
Vcc = 50 Volts
PW = 10
碌sec
DF = 1%
F = 1090 MHz
Ie = 15 mA
Ic = 25 mA
Vcb = 50 Volts
Ic = 250 mA, Vce = 5 V
MIN
150
25
7.8
8.3
40
20:1
4.0
55
20
0.6
o
TYP
MAX
UNITS
Watts
Watts
dB
%
Volts
Volts
pF
C/W
胃jc
2
Note 1: At rated output power and pulse conditions
2: At rated pulse conditions
Initial Issue June 1, 1994
GHz TECHNOLOGY INC. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. GHz RECOMMENDS THAT
BEFORE THE PRODUCT(S) DESCRIBED HEREIN ARE WRITTEN INTO SPECIFICATIONS, OR USED IN CRITICAL APPLICATIONS,
THAT THE PERFORMANCE CHARACTERISTICS BE VERIFIED BY CONTACTING THE FACTORY.
GHz Technology Inc. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 / 986-8120
