MICROCIRCUIT DATA SHEET

MNDM54LS32-X REV 1A0

QUAD 2-INPUT OR GATE

General Description

This device contains four independent gates, each of which perform the logic OR function.

Original Creation Date: 04/22/98

Last Update Date: 06/16/98

Last Major Revision Date: 04/22/98

Industry Part Number

54LS32

NS Part Numbers

DM54LS32E/883

DM54LS32J/883

DM54LS32W/883

Prime Die

L032

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1
