MICROCIRCUIT DATA SHEET

MNDM54LS241-X REV 1A0

Original Creation Date: 04/31/98

Last Update Date: 08/24/98

Last Major Revision Date: 04/31/98

OCTAL BUFFERS/LINE DRIVERS (with 3-state outputs)

General Description

The 'LS241 is an octal buffer and line driver designed to be employed as memory address

drivers, clock drivers and bus-oriented transmitter/receivers which provide improved PC

board density.

Industry Part Number

54LS241

NS Part Numbers

DM54LS241J/883

Prime Die

L241

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1

next
