DK1001R
16
Typical Applications
鈥?Remote Keyless Entry
鈥?Wireless Security Systems
鈥?Remote Monitoring
鈥?Remote Controls
433MHZ REMOTE KEYLESS ENTRY RECEIVER
Product Description
The DK1001R is the receiver half of our remote keyless
entry system evaluation kit. It is designed to allow the
user to easily and quickly demonstrate the operation of
the RF2919 in a typical application. Everything needed to
demonstrate a one way receiver is included. The RF2919
is setup to demonstrate a typical keyless entry system
using a rolling code decoder while operating at 433MHz.
A battery is included and the antenna is printed on the cir-
cuit board. This unit is designed to work with the mating
transmitter, DK1001T.
Optimum Technology Matching廬 Applied
眉
Si Bi-CMOS
IF
Filter
Si BJT
GaAs HBT
SiGe HBT
GaAs MESFET
Si CMOS
Features
鈥?Complete Receiver
鈥?Programmable Rolling Code Decoder
鈥?LED and Buzzer Indicators
鈥?Mates with DK1001T Transmitter
鈥?Battery and Antenna
Antenna
RSSI
Rolling
Code
Decoder
T1
S1
S2
S3
梅64/65
or
梅128/129
RF2919
F
RX
/n
Ordering Information
DK1001R
DK1001R
433MHz Remote Keyless Entry Receiver
Available only as part of the DK1001 Reference
Design Kit
Tel (336) 664 1233
Fax (336) 664 0454
http://www.rfmd.com
16
REF. DESIGNS &
DESIGN KITS
Functional Block Diagram
RF Micro Devices, Inc.
7625 Thorndike Road
Greensboro, NC 27409, USA
Rev A1 020109
16-25
