DIM800NSM33-F Datasheet

  • DIM800NSM33-F

  • IGBT Modules - Single Switch

  • 9頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DIM800NSM33-F000
DIM800NSM33-F000
Single Switch IGBT Module
PDS5615-1.1 June 2003
FEATURES
I
I
I
I
KEY PARAMETERS
V
CES
V
CE(sat)
*
I
C
I
C(PK)
(typ)
(max)
(max)
3300V
3.0V
800A
1600A
Soft Punch Through Silicon
10碌s Short Circuit Withstand
Isolated MMC Base with AlN Substrates
High Thermal Cycling Capability
*(measured at the auxiliary terminals)
APPLICATIONS
I
I
I
I
External connection
C1
Aux C
C2
High Reliability Inverters
Motor Controllers
Traction Drives
Choppers
The Powerline range of high power modules includes half
bridge, chopper, bi-directional, dual and single switch
configurations covering voltages from 600V to 3300V and
currents up to 3600A.
The DIM800NSM33-F000 is a single switch 3300V, soft
punch through, n channel enhancement mode, insulated gate
bipolar transistor (IGBT) module. The IGBT has a wide reverse
bias safe operating area (RBSOA) plus full 10碌s short circuit
withstand. This device is optimised for traction drives and other
applications requiring high thermal cycling capability.
The module incorporates an electrically isolated base plate
and low inductance construction enabling circuit designers to
optimise circuit layouts and utilise grounded heat sinks for safety.
G
Aux E
E1
E2
External connection
Fig. 1 Single switch circuit diagram
C
1
E1
E
2
G
C1
ORDERING INFORMATION
Order As:
DIM800NSM33-F000
Note: When ordering, please use the whole part number.
E
2
- Aux Emitter
C
1
- Aux Collector
E2
C2
Outline type code:
N
(See package details for further information)
Fig. 2 Electrical connections - (not to scale)
Caution: This device is sensitive to electrostatic discharge. Users should follow ESD handling procedures.
1/9
www.dynexsemi.com
