DIM200WKS12-A Datasheet

  • DIM200WKS12-A

  • IGBT Modules - Chopper

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DIM200WKS12-A000
DIM200WKS12-A000
IGBT Chopper Module - Upper Arm Control
Replaces December 2003 version, issue FDS5969-1.1
PDS5969-2.0 February 2004
FEATURES
I
I
I
10碌s Short Circuit Withstand
Non Punch Through Silicon
Isolated Copper Baseplate
KEY PARAMETERS
V
CES
(typ)
V
CE(sat)
*
(max)
I
C
(max)
I
C(PK)
1200V
2.2V
200A
400A
*(Measured at the power busbars and not the auxiliary terminals)
APPLICATIONS
I
I
I
I
I
Choppers
Motor Controllers
Induction Heating
Resonant Converters
Power Supplies
4(G
1
)
5(E
1
)
1(K,E)
2(A)
3(C1)
The Powerline range of high power modules includes half
bridge, chopper, dual, single and bi-directional switch
configurations covering voltages from 600V to 3300V and
currents up to 3600A.
The DIM200WKS12-A000 is a 1200V, n channel
enhancement mode, insulated gate bipolar transistor (IGBT)
chopper module configured with the upper arm of the bridge
controlled. The IGBT has a wide reverse bias safe operating
area (RBSOA) plus full 10碌s short circuit withstand.
The module incorporates an electrically isolated base plate
and low inductance construction enabling circuit designers to
optimise circuit layouts and utilise grounded heat sinks for safety.
Fig. 1 Chopper circuit diagram
ORDERING INFORMATION
Order As:
DIM200WKS12-A000
Note: When ordering, please use the whole part number.
Outline type code: W
(See package details for further information)
Fig. 2 Electrical connections - (not to scale)
Caution: This device is sensitive to electrostatic discharge. Users should follow ESD handling procedures.
1/8
www.dynexsemi.com
