DIM1200ESM33-A000
DIM1200ESM33-A000
Single Switch IGBT Module
Replaces June 2002, version DS5492-4.0
DS5492-5.0 February 2003
FEATURES
I
I
I
I
KEY PARAMETERS
V
CES
V
CE(sat)
*
I
C
I
C(PK)
(typ)
(max)
(max)
3300V
3.2V
1200A
2400A
10碌s Short Circuit Withstand
High Thermal Cycling Capability
Non Punch Through Silicon
Isolated MMC Base with AlN Substrates
*(measured at the power busbars and not the auxiliary terminals)
APPLICATIONS
I
I
I
External connection
C1
Aux C
C2
C3
High Reliability Inverters
Motor Controllers
Traction Drives
The Powerline range of high power modules includes half
bridge, chopper, dual and single switch configurations covering
voltages from 600V to 3300V and currents up to 2400A.
The DIM1200ESM33-A000 is a single switch 3300V, n
channel enhancement mode, insulated gate bipolar transistor
(IGBT) module. The IGBT has a wide reverse bias safe
operating area (RBSOA) plus full 10碌s short circuit withstand.
This device is optimised for traction drives and other applications
requiring high thermal cycling capability.
The module incorporates an electrically isolated base plate
and low inductance construction enabling circuit designers to
optimise circuit layouts and utilise grounded heat sinks for safety.
G
Aux E
E1
E2
External connection
Fig. 1 Single switch circuit diagram
E3
ORDERING INFORMATION
Order As:
DIM1200ESM33-A000
Note: When ordering, please use the whole part number.
Outline type code:
E
(See package details for further information)
Fig. 2 Electrical connections - (not to scale)
Caution: This device is sensitive to electrostatic discharge. Users should follow ESD handling procedures.
1/10
www.dynexsemi.com
