DGT305RE

DGT305RE

Reverse Blocking Gate Turn-off Thyristor

DS5519-2.0 February 2002

FEATURES

s

s

s

s

s

s

s

KEY PARAMETERS

I

TCM

700A

1800V

240A

500V/

碌

s

500A/

碌

s

Double Side Cooling

Reverse Blocking Capability

High Reliability In Service

High Voltage Capability

Fault Protection Without Fuses

High Surge Current Capability

Turn-off Capability Allows Reduction In Equipment

Size And Weight. Low Noise Emission Reduces

Acoustic Cladding Necessary For Environmental

Requirements

V

DRM

I

T(AV)

dV

D

/dt

di

T

/dt

APPLICATIONS

s

s

s

s

s

s

s

Variable speed A.C. motor drive inverters (VSD-AC)

Uninterruptable Power Supplies

High Voltage Converters

Choppers

Welding

Induction Heating

DC/DC Converters

Outline type code:

E

(See Package Details for further information)

Fig. 1 Package outline

VOLTAGE RATINGS

Type Number

Repetitive Peak Off-state Voltage Repetitive Peak Reverse Voltage

V

DRM

V

RRM

V

V

1800

1800

Conditions

DGT305SE18

T

vj

= 125

o

C, I

DM

= 50mA,

I

RRM

= 50mA, V

RG

= 2V

1/13

www.dynexsemi.com

next
