DG758BX45
DG758BX45
Gate Turn-off Thyristor
Replaces March 1998 version, DS4095-5.3
DS4095-6.0 January 2000
APPLICATIONS
s
Variable speed A.C. motor drive inverters (VSD-AC).
s
Uninterruptable Power Supplies
s
High Voltage Converters.
s
Choppers.
s
Welding.
s
Induction Heating.
s
DC/DC Converters.
KEY PARAMETERS
3000A
I
TCM
V
DRM
4500V
870A
I
T(AV)
dV
D
/dt
1000V/
碌
s
300A/
碌
s
di
T
/dt
FEATURES
s
Double Side Cooling.
s
High Reliability In Service.
s
High Voltage Capability.
s
Fault Protection Without Fuses.
s
High Surge Current Capability.
s
Turn-off Capability Allows Reduction In Equipment
Size And Weight. Low Noise Emission Reduces Acoustic
Cladding Necessary For Environmental Requirements.
Outline type code: X.
See Package Details for further information.
VOLTAGE RATINGS
Type Number
Repetitive Peak Off-state Voltage Repetitive Peak Reverse Voltage
V
RRM
V
DRM
V
V
4500
16
Conditions
DG758BX45
T
vj
= 125
o
C, I
DM
= 100mA,
I
RRM
= 50mA
CURRENT RATINGS
Symbol
I
TCM
I
T(AV)
I
T(RMS)
Parameter
Conditions
Max.
3000
870
1365
Units
A
A
A
Repetitive peak controllable on-state current V
D
= 66% V
DRM
, T
j
= 125
o
C, di
GQ
/dt = 40A/碌s, Cs = 6碌F
Mean on-state current
RMS on-state current
T
HS
= 80
o
C. Double side cooled. Half sine 50Hz.
T
HS
= 80
o
C. Double side cooled. Half sine 50Hz.
1/19
