DG2003/2004/2005
New Product
Vishay Siliconix
Low-Voltage Dual SPST Analog Switch
FEATURES
D
D
D
D
D
D
D
Low Voltage Operation (1.8 V to 5.5 V)
Low On-Resistance - r
DS(on
): 1.2
W
Fast Switching - 14 ns
Low Charge Injection - Q
INJ
: 1 pC
Low Power Consumption
TTL/CMOS Compatible
MSOP-8 Package
BENEFITS
D
D
D
D
Reduced Power Consumption
Simple Logic Interface
High Accuracy
Reduce Board Space
APPLICATIONS
D
D
D
D
D
Cellular Phones
Communication Systems
Portable Test Equipment
Battery Operated Systems
Sample and Hold Circuits
DESCRIPTION
The DG2003/2004/2005 are dual single-pole/single-throw
monolithic CMOS analog switch designed for high
performance switching of analog signals. Combining low
power, fast switching, low on-resistance (r
DS(on)
: 1.2
W)
and
small physical size (MSOP-8), the DG2003/2004/2005 are
ideal for portable and battery powered applications requiring
high performance and efficient use of board space.
The DG2003/2004/2005 are built on Vishay Siliconix鈥檚 low
voltage JI2 process. An epitaxial layer prevents latchup.
Each switch conducts equally well in both directions when on,
and blocks up to the power supply level when off.
FUNCTIONAL BLOCK DIAGRAM AND PIN CONFIGURATION
DG2003
NO
1
COM
1
IN
2
GND
V+
IN
1
COM
2
NO
2
NC
1
COM
1
IN
2
GND
DG2004
V+
IN
1
COM
2
NC
2
NO
1
COM
1
IN
2
GND
DG2005
V+
IN
1
COM
2
NC
2
1
2
3
4
8
7
6
5
1
2
3
4
8
7
6
5
1
2
3
4
8
7
6
5
Top View
Top View
Top View
TRUTH TABLE - DG2003
Logic
0
1
TRUTH TABLE - DG2004
Logic
0
1
TRUTH TABLE - DG2005
Logic
0
1
NO
Off
On
NC
On
Off
NO
1
Off
On
NC
2
On
Off
ORDERING INFORMATION
Temp Range
-40 to 85擄C
Package
MSOP-8
Part Number
DG2003DQ
DG2004DQ
DG2005DQ
Document Number: 71754
S-05298鈥擱ev. B, 17-Dec-01
www.vishay.com
1
