1.1mm Pitch Low Profile Compression Connectors

DF26 Series

Compression Connectors

-Mating height: 1.2mm and 1.7mm

Press down

Press in

Features

1. Low Profile

Connectors are available in heights : 1.2mm and

1.7mm.

3. One-Piece Connector

These connectors support cost reduction requirement

since there is no need for a mating half connector.

This design also permits a reduction in the number of

assembly steps.

2. Miniature, Space-Saving Design

The space-saving design of these connectors permits

increase in the mounting density as compared to

equivalent products.

4. Variations

Number of Contacts

Mating Height

1.2mm

1.7mm

9 Contacts 16 Contacts 18 Contacts

鉁?/div>

Under development

Applications

LCD, cellular phones, notebook computers, miniature office automation

equipment, and miniature consumer products.

Item

Product

Before Contact

Contacting (Effective Mating Height)

1.55mm

1.2mm

Press

down

1.9mm

1.55mm

1.2mm

2.05mm

Press

down

1.2mm

1.7mm

2.4mm

2.05mm

1.7mm

2003.7
