DF15SC4M Datasheet

  • DF15SC4M

  • Schottky Rectifiers (SBD) (40V 15A)

  • 10頁

  • SHINDENGEN   SHINDENGEN

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

SHINDENGEN
Schottky Rectifiers (SBD)
Dual
DF15SC4M
40V 15A
FEATURES
鈼?/div>
SMT
鈼?/div>
Tj150鈩?/div>
鈼?/div>
P
RRSM
鈼?/div>
High
OUTLINE DIMENSIONS
Case : STO-220
Unit : mm
avalanche guaranteed
current capacity with Small Package
APPLICATION
鈼?/div>
Switching power supply
鈼?/div>
DC/DC converter
鈼?/div>
Home Appliances, Office
鈼?/div>
Telecommunication
Equipment
RATINGS
鈼廇bsolute Maximum Ratings (If not specified Tc=25鈩?
Item
Symbol
Conditions
Storage Temperature
Tstg
Operating Junction Temperature
Tj
Maximum Reverse Voltage
V
RM
Repetitive Peak Surge Reverse Voltage
V
RRSM
Pulse width 0.5ms, duty 1/40
I
O
Average Rectified Forward Current
50Hz sine wave, R-load, Tc=129鈩?/div>
Peak Surge Forward Current
I
FSM
50Hz sine wave, Non-repetitive 1 cycle peak value, Tj=125鈩?/div>
Repetitive Peak Surge Reverse Power
P
RRSM
Pulse width 10渭s, Rating of per diode, Tj= 25鈩?/div>
鈼廍lectrical Characteristics (If not specified
Item
Symbol
Forward Voltage
V
F
Reverse Current
I
R
Junction Capacitance
Cj
Thermal Resistance
胃jc
Tc=25鈩?
Conditions
I
F
=7.5A, Pulse measurement, Rating of per diode
V
R
=V
RM
, Pulse measurement, Rating of per diode
f=1MHz, V
R
=10V, Rating of per diode
junction to case
Ratings
-40鈭?50
150
40
45
15
150
330
Ratings
Max.0.55
Max.5
Typ.340
Max.1.7
Unit
鈩?/div>
鈩?/div>
V
V
A
A
W
Unit
V
pF
鈩?W
Copyright & Copy;2000 Shindengen Electric Mfg.Co.Ltd

DF15SC4M 產品屬性

  • Shindengen

  • Schottky Rectifiers

  • 40 V

  • 15 A

  • 150 A

  • Dual Common Cathode

  • 0.55 V at 7.5 A

  • 5000 uA

  • + 150 C

  • SMD/SMT

  • STO-220

  • Reel - 13 in
