DF14-3S-1.25C Datasheet

  • DF14-3S-1.25C

  • 1.25mm Pitch Super Low profile Crimping Connector

  • 6頁

  • HRS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

1.25mm Pitch Super Low profile Crimping Connector
DF14 Series
sFeatures
1. Super Low Profile
This is a connector special for right angle which has pursued a low
profile on the board.
Board mounting height:
2.5mm
A signal can be fetched from the area where there is no board to
board space.
Board Mounting Figure
2. Correspond to Automatic Mounting
The header has the vacuum mount face which enables the vacuum
absorption and the automatic mounting by the embossed tape
packaging.In addition, the tube packaging can be selected.
3. Four Wall Type Without Friction to Board by Socket
The header has the box structure to prevent from being twisted and
has the perfect mis-insertion prevention method. Moreover the
header has the wall on the board side and doesn't have any trouble
resulted from the friction to board by socket.
In addition, the metal fitting is attached to prevent the solder peel.
1
sApplications
LCD, Note PC, Mobile Terminal Small business equipment, Video camera
B177

DF14-3S-1.25C 產品屬性

  • Board-to-Wire Connectors

  • 100

  • 連接器，互連式

  • 矩形 - 外殼

  • DF14

  • 插座

  • 母形插口

  • 3

  • 0.049"（1.25mm）

  • 1

  • -

  • 自由懸掛

  • 壓接

  • -

  • 淺褐

  • -

  • 散裝

  • 不提供觸點

  • H10341DKR-ND - CONN HEADER 3POS 1.25MM R/A SMDH10340DKR-ND - CONN HEADER 3POS 1.25MM R/A SMDH10315DKR-ND - CONN HEADER 3POS 1.25MM R/A SMDH10341CT-ND - CONN HEADER 3POS 1.25MM R/A SMDH10340CT-ND - CONN HEADER 3POS 1.25MM R/A SMDH10315CT-ND - CONN HEADER 3POS 1.25MM R/A SMDH10341TR-ND - CONN HEADER 3POS 1.25MM R/A SMDH10340TR-ND - CONN HEADER 3POS 1.25MM R/A SMDH10315TR-ND - CONN HEADER 3POS 1.25MM R/A SMDH10341-ND - CONN HEADER 3POS 1.25MM R/A SMD更多...

  • H1579CT-ND - CONN TERM 30-32AWG CRIMP GOLDH1578CT-ND - CONN TERM 30-32AWG CRIMP TINH1577CT-ND - CONN TERM 26-28AWG CRIMP GOLDH1576CT-ND - CONN TERM 26-28AWG CRIMP TINH1579TR-ND - CONN TERM 30-32AWG CRIMP GOLDH1578TR-ND - CONN TERM 30-32AWG CRIMP TINH1577TR-ND - CONN TERM 26-28AWG CRIMP GOLDH1576TR-ND - CONN TERM 26-28AWG CRIMP TIN

  • *DF14-3S-1.25CH1564
