DES9208901AC Datasheet

  • DES9208901AC

  • 1GHz ± 16/17, ±32/33 Multi-Modulus Divider

  • 8頁

  • MITEL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

SP8782A & B
SP8782A & B
1GHz
梅
16/17,
梅
32/33 Multi-Modulus Divider
DS3651
Issue 2.4
June 1999
Features
q
q
q
q
Advanced Resynchronisation techniques to negate
loop delay effects
CMOS compataible output capability
Multi-Modulus division
Available as DESC SMD 5962-9208901MPA
Odering Information
SP8782 A DG
SP8782 B MP
DES9208901/AC/DGAZ(SMD)
Description
The SP8782 is a multi-modulus divider which divides by 16/
17 when the Ratio Select input is low and by 32/33 when
theRatio Select input is high. When high, the modulus Control
input selects the lower division ratio (16 or 32) and the higher
ratio (17 or 33) when it is low.
The device uses resynchronisation techniques to reduce the
effects of propagation delays in frequency synthesis.
The SP8782A (ceramic DIL package) is characterised over
the full military temperature range of -55擄C to +125擄C, the
SP8782B (miniature plastic DIL package) over the industrial
range of -40擄C to+85擄C.
Absolute Maximum Ratings
Supply Voltage
Clock input level
Junction temperature
Storage temperature range:
SP8782A
SP8782B
6V
2.5V p-p
+175擄C
-55擄C to +150擄C
-55擄C to +125擄C
RATIO
SELECT
1
V
CC
2
CLOCK INPUT
CLOCK INPUT
2
3
梅
16/17
梅
32/33
7
OUTPUT
4
V
EE
5
MODULUS
CONTROL
INPUT
Figure 1 Functional Diagram
1
