DDTA
(R1 = R2 SERIES)
KA
PNP PRE-BIASED SMALL SIGNAL SC-59
SURFACE MOUNT TRANSISTOR
Features
NEW PRODUCT
路
路
路
Epitaxial Planar Die Construction
Complementary NPN Types Available
(DDTC)
Built-In Biasing Resistors, R1 = R2
IN
A
OUT
B C
SC-59
Dim
Min
0.35
1.50
2.70
0.95
1.90
2.90
0.013
1.00
0.35
0.10
0擄
3.10
0.10
1.30
0.55
0.20
8擄
Max
0.50
1.70
3.00
A
B
C
M
Mechanical Data
路
路
路
路
路
路
路
路
Case: SC-59, Molded Plastic
Case material - UL Flammability Rating 94V-0
Moisture sensitivity: Level 1 per J-STD-020A
Terminals: Solderable per MIL-STD-202,
Method 208
Terminal Connections: See Diagram
Marking: Date Code and Marking Code
(See Diagrams & Page 2)
Weight: 0.008 grams (approx.)
Ordering Information (See Page 2)
IN
K
GND
G
H
D
G
H
J
K
J
D
L
R
1
R
2
OUT
L
M
a
All Dimensions in mm
P/N
DDTA123EKA
DDTA143EKA
DDTA114EKA
DDTA124EKA
DDTA144EKA
DDTA115EKA
R1, R2 (NOM) MARKING
2.2KW
4.7KW
10KW
22KW
47KW
100KW
P04
P08
P13
P17
P20
P24
GND
IN
GND
SCHEMATIC DIAGRAM
OUT
Maximum Ratings
Supply Voltage, (3) to (1)
Input Voltage, (2) to (1)
@ T
A
= 25擄C unless otherwise specified
Symbol
V
CC
DDTA123EKA
DDTA143EKA
DDTA114EKA
DDTA124EKA
DDTA144EKA
DDTA115EKA
DDTA123EKA
DDTA143EKA
DDTA114EKA
DDTA124EKA
DDTA144EKA
DDTA115EKA
All
Value
-50
+10 to -12
+10 to -30
+10 to -40
+10 to -40
+10 to -40
+10 to -40
-100
-100
-50
-30
-100
-20
-100
200
625
-55 to +150
Unit
V
Characteristic
V
IN
V
Output Current
I
O
mA
Output Current
Power Dissipation
Thermal Resistance, Junction to Ambient Air (Note 1)
Operating and Storage and Temperature Range
Note:
I
C
(Max)
P
d
R
qJA
T
j
, T
STG
mA
mW
擄C/W
擄C
1. Mounted on FR4 PC Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.
DS30341 Rev. 3 - 2
1 of 3
DDTA (R1 = R2 SERIES) KA
1
2
3
