VOLTAGE CONTROLLED OSCILLATOR
SURFACE MOUNT MODEL:
DCMO110250-8
WIDE BANDWIDTH
FEATURES:
鈻?/div>
Exceptional Phase Noise Performance
鈻?/div>
Small Size, Surface Mount
鈻?/div>
Lead Free REL-PRO
廬
Technology
Phase Noise
-40
-50
-60
-70
1100 - 2500 MHz
Phase Noise (dBc/Hz)
-80
-90
-100
-110
-120
-130
-140
-150
-160
-170
100
1000
1100.6MHz/1.95V
2154.3MHz/15V
10000
100000
1000000
1767.8MHz/10V
10000000
Offset Frequency (Hz)
1352.5MHz/5V
2500.3MHz/22.92V
SPECIFICATIONS (Rev. C 08/06/07)
Frequency
Tuning Voltage
Bias Voltage
Output Power
Tuning Sensitivity
Output Impedance
Harmonic Suppression
Frequency Pulling
Frequency Pushing
Tuning Port Capacitance
Phase Noise @ 10 kHz
Operating Temperature Range
Guaranteed Tuning Speci鏗乧ations
Tuning Voltage ( V )
0.5
5
8
12
15
18
24
28
Absolute Maximum Ratings
Storage Temp. Range
Bias Voltage
Tuning Voltage
DC Voltage Applied to RF Out
-55 to +125 潞C
+8.5 V
+30 V
鹵 25 V
Frequency ( MHz )
1100 (Max)
1250 (Min)
1500 (Min)
1800 (Min)
2050 (Min)
2200 (Min)
2400 (Min)
2500 (Min)
1100 - 2500 MHz
See table below.
+8 VDC @ 35 mA (Max.)
+4 dBm (Min.)
30 - 90 MHz/V (Typ.)
50 Ohms (Nom.)
15 dB (Typ.)
5 MHz (Typ. @ 1.75:1 VSWR)
5 MHz/V (Typ.)
50 pF (Typ.)
-102 dBc/Hz (Typ.)
-40 to +85 擄C
Package #
278LF
