Ordering number:EN4706
DCG10
Silicon Epitaxial Planar Type (Twin Type, Anode Common)
High-Speed Rectifiers,
High-Frequency Rectifiers
Features
路 Ideal for use in hybrid ICs because of small-sized
package.
Package Dimensions
unit:mm
1239A
[DCG10]
1:Anode
2:Cathode
3:Anode
SANYO:PCP
(Bottom view)
Specifications
Absolute Maximum Ratings
at Ta = 25藲C
Parameter
Peak Reverse Voltage
Reverse Voltage
Surge Forward Current
Average Rectified Current
Peak Forward Current
Junction Temperature
Storage Temperature
Symbol
VRM
VR
IFSM
IO
IO
IFM
IFM
Tj
Tstg
Total value
Total value
50Hz sine wave, 1 cycle
Conditions
Ratings
200
200
5
1.0
1.5
2.0
3.0
150
鈥?0 to +150
Unit
V
V
A
A
A
A
A
藲C
藲C
Electrical Characteristics
at Ta = 25藲C
Parameter
Reverse Voltage
Forward Voltage
Reverse Current
Interterminal Capacitance
Reverse Recovery Time
Thermal Resistance
Symbol
VR
VF
IR
C
trr
Rth(j-a)1
Rth(j-a)2
IF=10碌A(chǔ)
IF=1A
VR=200V
VR=30V, f=1MHz
IF=1A, 鈥揹IF/dt=10A/碌s
4.0
90
300
2
Conditions
Ratings
min
200
1.0
1.3
10
300
typ
max
Unit
V
V
碌A(chǔ)
pF
ns
藲C/W
藲C/W
Mounted on ceramic board (250mm
脳0.8mm)
100
Marking:PB
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters
TOKYO OFFICE, Tokyo Bldg., 1-10 , Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
52098HA (KT)/30195MO (KOTO) AX-8089 No.4706-1/2
