DB101G THRU DB107G
GLASS PASSIVATED SINGLE-PHASE BRIDGE RECTIFIER
Reverse Voltage - 50 to 1000 Volts
Forward Current - 1.0 Ampere
DFM
FEATURES
0.255(6.5)
0.245(6.2)
0.315(8.00)
0.265(7.24)
0.335(8.51)
0.320(8.12)
0.130(3.30)
0.120(3.05)
0.045(1.14)
0.035(0.89)
0.023(0.58)
0.018(0.46)
0.205(5.2)
0.195(5.0)
0.080(2.03)
0.050(1.27)
0.185(4.69)
0.150(3.81)
0.075(1.90)
0.055(1.39)
0.013(3.3)
0.0086(0.22)
0.350(8.9)
0.300(7.6)
* This series is UL listed under the Recognized Component
Index, file number E-96005
* Surge overload rating of 50 Amperes peak
* Ideal for printed circuit board
* Reliable low cost construction utilizing molded plastic technique
o
* High temperature soldering guaranteed: 260 C/10 seconds,
0.375" (9.5mm) lead length, 5lbs. (2.3 kg) tension
* Plastic package has Underwriters Laboratory Flammability
Classification 94V-0
MECHANICAL DATA
Case :
JEDEC DFM molded plastic body over passivated junction
Terminals :
Plated leads solderable per MIL-STD-750,
Method 2026
Polarity :
Color band denotes cathode end
Mounting Position :
Any
Weight :
0.04 ounes , 1.0 gram
*Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature
SYMBOLS
unless otherwise specified.
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current @T
A
=40 C
o
o
DB
101G
102G
100
70
100
UNITS
105G
600
420
600
103G
200
140
200
104G
400
280
400
106G
800
560
800
107G
1000
700
1000
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
Volts
Volts
Volts
Amps
1.0
Peak forward surge current 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum instantaneous forward voltage at 1.0 A
Maximum reverse current
at rated DC blocking voltage per element
Typical junction capacitance (NOTE 1)
Typical thermal resistance (NOTE 2)
Operating junction and storage temperature range
@T
A
=25 C
@T
A
=125 C
o
o
I
FSM
50
Amps
V
F
1.1
10
Volts
I
R
500
25
40
15
-55 to +150
o
uA
C
J
R
R
JA
JL
pF
C/W
o
T
J
,T
STG
C
NOTES : (1) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts
(2) Thermal resistance from junction to ambient and from junction to lead mounted on P.C.B. with 0.5 X0.5" (13 X 13mm) copper pads
REV. : 0
Zowie Technology Corporation
