CZTA44HC
SURFACE MOUNT
NPN SILICON HIGH CURRENT
HIGH VOLTAGE
TRANSISTOR
Central
DESCRIPTION:
TM
Semiconductor Corp.
The CENTRAL SEMICONDUCTOR CZTA44HC
type is a surface mount epoxy molded silicon
planar epitaxial transistors designed for
extremely high voltage and high current
applications.
SOT-223 CASE
MAXIMUM RATINGS:
(TA=25擄C)
SYMBOL
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Collector Current (PeaK)
Power Dissipation
Operating and Storage
Junction Temperature
Thermal Resistance
VCBO
VCEO
VEBO
IC
ICM
PD
TJ,Tstg
螛
JA
450
400
7.0
2.0
3.0
2.0
65 to +150
62.5
UNITS
V
V
V
A
A
W
擄C
擄C/W
ELECTRICAL CHARACTERISTICS:
(TA=25擄C unless otherwise noted)
SYMBOL
TEST CONDITIONS
MIN
ICBO
IEBO
BVCBO
BVCEO
BVEBO
VCE(SAT)
VCE(SAT)
VCE(SAT)
VBE(SAT)
hFE
hFE
hFE
hFE
fT
Cob
Cib
VCB=400V
VBE=5.0V
IC=50碌A
IC=1.0mA
IE=50碌A
IC=500mA, IB=50mA
IC=1.0A, IB=100mA
IC=2.0A,
IC=1.0A,
IB=200mA
IB=1.0mA
35
35
30
15
10
450
400
7.0
MAX
500
500
UNITS
nA
nA
V
V
V
0.25
0.50
1.5
1.5
V
V
V
V
VCE=10V, IC=10mA
VCE=10V, IC=500mA
VCE=10V, IC=1.0A
VCE=10V, IC=2.0A
VCE=10V, IC=10mA, f=10MHz
VCB=20V, IE=0, f=1.0MHz
VEB=0.5V, IC=0, f=1.0MHz
MHz
30
1000
pF
pF
