CZTA28
SURFACE MOUNT
NPN DARLINGTON TRANSISTOR
Central
TM
Semiconductor Corp.
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CZTA28
type is a NPN Silicon Darlington Transistor
manufactured by the epitaxial planar process,
epoxy molded in a surface mount package,
designed for applications requiring extremely
high gain.
SOT-223 CASE
MAXIMUM RATINGS:
(TA=25擄C)
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage
Collector Current
Power Dissipation
Operating and Storage
Junction Temperature
Thermal Resistance
TJ,Tstg
螛
JA
-65 to +150
62.5
擄C
擄C/W
SYMBOL
VCES
VCBO
VEBO
IC
PD
80
80
12
500
2.0
UNITS
V
V
V
mA
W
ELECTRICAL CHARACTERISTICS:
(TA=25擄C unless otherwise noted)
SYMBOL
ICBO
ICES
IEBO
BVCBO
BVCES
BVEBO
VCE(SAT)
VCE(SAT)
VBE(ON)
hFE
hFE
fT
Cob
TEST CONDITIONS
VCB=60V
VCE=60V
VEB=10V
IC=100碌A
IC=100碌A
IE=10碌A
IC=10mA, IB=10碌A
IC=100mA, IB=100碌A
VCE=5.0V,
VCE=5.0V,
IC=100mA
IC=10mA
80
80
12
1.2
1.5
2.0
10,000
10,000
125
8.0
MHz
pF
MIN
MAX
100
500
100
UNITS
nA
nA
nA
V
V
V
V
V
V
VCE=5.0V, IC=100mA
VCE=5.0V, IC=10mA, f=100MHz
VCB=10V, IE=0, f=100kHz
R0 ( 13-November 2001)
1
2
