CY7C138
CY7C139
4K x 8/9 Dual-Port Static RAM
Features
鈥?True Dual-Ported memory cells which allow
simultaneous reads of the same memory location
鈥?4K x 8 organization (CY7C138)
鈥?4K x 9 organization (CY7C139)
鈥?0.65-micron CMOS for optimum speed/power
鈥?High-speed access: 15 ns
鈥?Low operating power: I
CC
= 160 mA (max.)
鈥?Fully asynchronous operation
鈥?Automatic power-down
鈥?TTL compatible
鈥?Expandable data bus to 32/36 bits or more using
Master/Slave chip select when using more than one
device
鈥?On-chip arbitration logic
鈥?Semaphores included to permit software handshaking
between ports
鈥?INT flag for port-to-port communication
鈥?Available in 68-pin PLCC
are included on the CY7C138/9 to handle situations when mul-
tiple processors access the same piece of data. Two ports are
provided permitting independent, asynchronous access for
reads and writes to any location in memory. The CY7C138/9
can be utilized as a standalone 8/9-bit dual-port static RAM or
multiple devices can be combined in order to function as a
16/18-bit or wider master/slave dual-port static RAM. An M/S
pin is provided for implementing 16/18-bit or wider memory
applications without the need for separate master and slave
devices or additional discrete logic. Application areas include
interprocessor/multiprocessor designs, communications sta-
tus buffering, and dual-port video/graphics memory.
Each port has independent control pins: chip enable (CE),
read or write enable (R/W), and output enable (OE). Two flags are
provided on each port (BUSY and INT). BUSY signals that the port is
trying to access the same location currently being accessed by the
other port. The interrupt flag (INT) permits communication between
ports or systems by means of a mail box. The semaphores are used
to pass a flag, or token, from one port to the other to indicate that a
shared resource is in use. The semaphore logic is comprised of eight
shared latches. Only one side can control the latch (semaphore) at
any time. Control of a semaphore indicates that a shared resource is
in use. An automatic power-down feature is controlled independently
on each port by a chip enable (CE) pin or SEM pin.
The CY7C138 and CY7C139 are available in a 68-pin PLCC.
Functional Description
The CY7C138 and CY7C139 are high-speed CMOS 4K x 8
and 4K x 9 dual-port static RAMs. Various arbitration schemes
Logic Block Diagram
R/W
L
CE
L
OE
L
R/W
R
CE
R
OE
R
(7C139)I/O
8L
I/O
7L
I/O
0L
BUSY
L
[1, 2]
A
11L
A
0L
ADDRESS
DECODER
I/O
CONTROL
I/O
CONTROL
I/O
8R
(7C139)
I/O
7R
I/O
0R
BUSY
R
A
11R
A
0R
[1, 2]
MEMORY
ARRAY
ADDRESS
DECODER
CE
L
OE
L
R/W
L
INTERRUPT
SEMAPHORE
ARBITRATION
CE
R
OE
R
R/W
R
SEM
L
INT
L
[2]
M/S
SEM
R
INT
R
[2]
C138-1
Notes:
1. BUSY is an output in master mode and an input in slave mode.
2. Interrupt: push-pull output and requires no pull-up resistor.
Cypress Semiconductor Corporation
鈥?/div>
3901 North First Street
鈥?/div>
San Jose
鈥?/div>
CA 95134
鈥?/div>
408-943-2600
November 1996
