25/0251

CY7C138AV/144AV/006AV

CY7C139AV/145AV/016AV

CY7C007AV/017AV

3.3V 4K/8K/16K/32K x 8/9

Dual-Port Static RAM

Features

鈥?True Dual-Ported memory cells which allow simulta-

neous access of the same memory location

鈥?4K/8K/16K/32K x 8 organizations

(CY7C0138AV/144AV/006AV/007AV)

鈥?4K/8K/16K/32K x 9 organizations

(CY7C0139AV/145AV/016AV/017AV)

鈥?0.35-micron CMOS for optimum speed/power

鈥?High-speed access: 20/25 ns

鈥?Low operating power

鈥?Active: I

= 115 mA (typical)

鈥?Standby: I

SB3

= 10

碌A(chǔ)

(typical)

鈥?Fully asynchronous operation

鈥?Automatic power-down

鈥?Expandable data bus to 16/18 bits or more using Master/

Slave chip select when using more than one device

鈥?On-chip arbitration logic

鈥?Semaphores included to permit software handshaking

between ports

鈥?INT flag for port-to-port communication

鈥?Pin select for Master or Slave

鈥?Commercial and Industrial Temperature Ranges

鈥?Available in 68-pin PLCC (all) and 64-pin TQFP

(7C006AV & 7C144AV)

鈥?Pin-compatible and functionally equivalent to

IDT70V05, 70V06, and 70V07.

Logic Block Diagram

R/W

[1]

8/9

[1]

I/O

鈥揑/O

7/8L

I/O

Control

I/O

Control

I/O

鈥揑/O

7/8R

[2]

12鈥?5

鈥揂

11鈥?4L

Address

Decode

12鈥?5

True Dual-Ported

RAM Array

Address

Decode

12鈥?5

[2]

鈥揂

11鈥?4R

[2]

鈥揂

11鈥?4L

R/W

SEM

[3]

Interrupt

Semaphore

Arbitration

鈥揂

11鈥?4R

R/W

SEM

[3]

BUSY

INT

M/S

Notes:

1. I/O

鈥揑/O

for x8 devices; I/O

鈥揑/O

for x9 devices.

2. A

鈥揂

for 4K devices; A

鈥揂

for 8K devices; A

鈥揂

for 16K devices; A

鈥揂

for 32K devices;

3. BUSY is an output in master mode and an input in slave mode.

BUSY

INT

For the most recent information, visit the Cypress web site at www.cypress.com

Cypress Semiconductor Corporation

鈥?3901 North First Street 鈥?San Jose 鈥?CA 95134 鈥?408-943-2600

Document #: 38-06051 Rev. *A

Revised December 27, 2002
