鈥?7.0 ns (for 80-MHz device)
Clock Enable (CEN) pin to suspend operation
Synchronous self-timed writes
Asynchronous output enable
JEDEC-standard 100 TQFP package
Burst Capability鈥攍inear or interleaved burst order
Low standby power (17.325 mW max.)
Functional Description
The CY7C1350B is a 3.3V, 128K by 36 synchronous-pipelined
Burst SRAM designed specifically to support unlimited true
back-to-back Read/Write operations without the insertion of
wait states. The CY7C1350B is equipped with the advanced
No Bus Latency鈩?(NoBL鈩? logic required to enable consec-
utive Read/Write operations with data being transferred on ev-
ery clock cycle. This feature dramatically improves the
throughput of the SRAM, especially in systems that require
frequent Write/Read transitions. The CY7C1350B is pin/func-
tionally
compatible
to
ZBT
SRAMs
IDT71V546,
MT55L128L36P, and MCM63Z736.
All synchronous inputs pass through input registers controlled
by the rising edge of the clock. All data outputs pass through
output registers controlled by the rising edge of the clock. The
clock input is qualified by the Clock Enable (CEN) signal, which
when deasserted suspends operation and extends the previ-
ous clock cycle. Maximum access delay from the clock rise is
3.5 ns (166-MHz device).
Write operations are controlled by the four Byte Write Select
(BWS
[3:0]
) and a Write Enable (WE) input. All writes are con-
ducted with on-chip synchronous self-timed write circuitry.
Three synchronous Chip Enables (CE
1
, CE
2
, CE
3
) and an
asynchronous Output Enable (OE) provide for easy bank se-
lection and output three-state control. In order to avoid bus
contention, the output drivers are synchronously three-stated
during the data portion of a write sequence.
Logic Block Diagram
CLK
D
Data-In REG.
CE Q
36
17
CONTROL
and WRITE
LOGIC
17
128Kx36
MEMORY
ARRAY
36
36
ADV/LD
A
[16:0]
CEN
CE
1
CE2
CE3
WE
BWS
[3:0]
MODE
CLK
OOUTPUT
REGISTERS
and LOGIC
36
DQ
[31:0]
DP
[3:0]
OE
.
Selection Guide
-166
Maximum Access Time (ns)
Maximum Operating Current (mA)
Maximum CMOS Standby Current (mA)
Shaded areas contain advance information.
NoBL and No Bus Latency are trademarks of Cypress Semiconductor Corporation.
ZBT is a trademark of Integrated Device Technology.
-150
3.8
375
5
-143
4.0
350
5
-133
4.2
300
5
-100
5.0
250
5
-80
7.0
200
5
3.5
Commercial
Commercial
400
5
Cypress Semiconductor Corporation
Document #: 38-05045 Rev. *A
鈥?/div>
3901 North First Street
鈥?/div>
San Jose
鈥?/div>
CA 95134 鈥?408-943-2600
Revised January 18, 2003
