CY74FCT825T
8-BIT BUS-INTERFACE REGISTER
SCCS070 鈥?OCTOBER 2001
D
D
D
D
D
D
D
D
D
D
Function, Pinout, and Drive Compatible
With FCT, F Logic, and AM29825
Reduced V
OH
(Typically = 3.3 V) Version of
Equivalent FCT Functions
Edge-Rate Control Circuitry for
Significantly Improved Noise
Characteristics
I
off
Supports Partial-Power-Down Mode
Operation
Matched Rise and Fall Times
Fully Compatible With TTL Input and
Output Logic Levels
ESD Protection Exceeds JESD 22
鈥?2000-V Human-Body Model (A114-A)
鈥?200-V Machine Model (A115-A)
鈥?1000-V Charged-Device Model (C101)
64-mA Output Sink Current
32-mA Output Source Current
High-Speed Parallel Register With
Positive-Edge-Triggered D-Type Flip-Flops
Buffered Common Clock-Enable (EN) and
Asynchronous-Clear (CLR) Inputs
Q PACKAGE
(TOP VIEW)
OE
1
OE
2
D
0
D
1
D
2
D
3
D
4
D
5
D
6
D
7
CLR
GND
1
2
3
4
5
6
7
8
9
10
11
12
24
23
22
21
20
19
18
17
16
15
14
13
V
CC
OE
3
Y
0
Y
1
Y
2
Y
3
Y
4
Y
5
Y
6
Y
7
EN
CP
description
This bus-interface register is designed to eliminate the extra packages required to buffer existing registers and
provide extra data width for wider address/data paths or buses carrying parity. The CY74FCT825T is an 8-bit
buffered register with all the CY74FCT823T controls, plus multiple enables (OE
1
, OE
2
, OE
3
) to allow multiuser
control of the interface, e.g., CS, DMA, and RD/WR. This device is ideal for use as an output port requiring high
I
OL
/I
OH
.
This device is designed for high-capacitance load drive capability, while providing low-capacitance bus loading
at both inputs and outputs. Outputs are designed for low-capacitance bus loading in the high-impedance state.
This device is fully specified for partial-power-down applications using I
off
. The I
off
circuitry disables the outputs,
preventing damaging current backflow through the device when it is powered down.
PIN DESCRIPTION
NAME
D
CLR
CP
Y
EN
OE
I/O
I
I
O
O
I
I
D flip-flop data inputs
When CLR is low and OE is low, Q outputs are low. When CLR is high, data can be entered into the register.
Clock pulse for the register. Enters data into the register on the low-to-high clock transition.
Register 3-state outputs
Clock enable. When EN is low, data on the D input is transferred to the Q output on the low-to-high clock transition. When
EN is high, the Q outputs do not change state, regardless of the data or clock input transitions.
Output control. When OE is high, the Y outputs are in the high-impedance state. When OE is low, true register data is present
at the Y outputs.
DESCRIPTION
