鈥?/div>
鈥?Typical Active Current: 4 mA @ f = f
max
(70 ns speed)
Low standby power
Easy memory expansion with CE
1
, CE
2
and OE features
Automatic power-down when deselected
CMOS for optimum speed/power
The device can also be put into standby mode when deselect-
ed (CE
1
HIGH or CE
2
LOW or both BHE and BLE are HIGH).
The input/output pins (I/O
0
through I/O
15
) are placed in a
high-impedance state when: deselected (CE
1
HIGH or CE
2
LOW), outputs are disabled (OE HIGH), both Byte High Enable
and Byte Low Enable are disabled (BHE, BLE HIGH), or during
a write operation (CE
1
LOW, CE
2
HIGH and WE LOW).
Writing to the device is accomplished by taking Chip Enables
(CE
1
LOW and CE
2
HIGH) and Write Enable (WE) inputs
LOW. If Byte Low Enable (BLE) is LOW, then data from I/O pins
(I/O
0
through I/O
7
), is written into the location specified on the
address pins (A
0
through A
18
). If Byte High Enable (BHE) is
LOW, then data from I/O pins (I/O
8
through I/O
15
) is written into
the location specified on the address pins (A
0
through A
18
).
Reading from the device is accomplished by taking Chip En-
able (CE
1
LOW and CE
2
HIGH) and Output Enable (OE) LOW
while forcing the Write Enable (WE) HIGH. If Byte Low Enable
(BLE) is LOW, then data from the memory location specified
by the address pins will appear on I/O
0
to I/O
7
. If Byte High
Enable (BHE) is LOW, then data from memory will appear on
I/O
8
to I/O
15
. See the truth table at the back of this datasheet
for a complete description of read and write modes.
The CY62157CV18 is available in a 48-ball FBGA package.
Functional Description
The CY62157CV18 is a high-performance CMOS static RAM
organized as 512K words by 16 bits. This device features ad-
vanced circuit design to provide ultra-low active current. This
is ideal for providing More Battery Life鈩?(MoBL鈩? in portable
applications such as cellular telephones. The device also has
an automatic power-down feature that significantly reduces
power consumption by 99% when addresses are not toggling.
Logic Block Diagram
DATA IN DRIVERS
A
10
A
9
A
8
A
7
A
6
A
5
A
4
A
3
A
2
A
1
A
0
ROW DECODER
512K x 16
RAM Array
2048 X 4096
SENSE AMPS
I/O
0
鈥揑/O
7
I/O
8
鈥揑/O
15
COLUMN DECODER
A
11
A
12
A
13
A
14
A
15
A
16
A
17
A
18
BHE
WE
OE
BLE
CE
2
CE
1
Pow
-
er Down
Circuit
BHE
BLE
CE
2
CE
1
MoBL, MoBL2, and More Battery Life are trademarks of Cypress Semiconductor Corporation.
Cypress Semiconductor Corporation
Document #: 38-05012 Rev. *C
鈥?/div>
3901 North First Street
鈥?/div>
San Jose
鈥?/div>
CA 95134 鈥?408-943-2600
Revised October 31, 2001
