CXP921F064A
CMOS 16-bit Single Chip Microcomputer
Description
The CXP921F064A is a CMOS 16-bit microcomputer
integrating on a single chip an A/D converter, serial
interface, I
2
C bus interface, timer, clock prescaler,
remote control receive circuit, and as well as basic
configurations like a 16-bit CPU, ROM, RAM, and I/O
port.
This LSI also provides the sleep/stop functions that
enable lower power consumption.
100 pin QFP (Plastic)
100 pin LQFP (Plastic)
104 pin LFLGA (Plastic)
Features
鈥?/div>
An efficient instruction set as a controller
鈥?Direct addressing, numerous abbreviated forms,
multiplication and division instructions
鈥?/div>
Instruction sets for C language and RTOS
鈥?Highly quadratic instruction system, general-
purpose register of 16-bit
脳
8-pin
脳
16-bank
configuration
鈥?/div>
Minimum instruction cycle
100ns at 20MHz operation (2.7 to 3.3V)
61碌s at 32kHz operation (2.2 to 3.3V)
鈥?/div>
Incorporated Flash ROM capacity
256K bytes
鈥?/div>
Incorporated RAM capacity
10K bytes
鈥?/div>
Peripheral functions
鈥?A/D converter
8-bit 12 analog input, 2 channels, successive approximation system,
automatic scanning function, (Conversion time: 3.4碌s at 20MHz)
鈥?Serial interface
128-byte buffer RAM, 3 channels
8-stage FIFO, 1 channel (supports special mode master/slave)
鈥?I
2
C bus interface
64-byte buffer RAM , 2 channels
(supports master/slave and automatic transfer mode)
鈥?Timers
8-bit timer/counter, 2 channels (with timing output)
16-bit timer, 3 channels
鈥?Real-time pulse generator
5-bit output, 1 channel (2-stage FIFO)
鈥?Clock prescaler
鈥?Remote control receive circuit 8-bit pulse measurement counter, 8-stage FIFO
鈥?/div>
Interruption
30 factors, 30 vectors, multi-interruption and priority selection possible
鈥?/div>
Standby mode
Sleep/stop
鈥?/div>
Package
100-pin plastic QFP/LQFP
104-pin plastic LFLGA
鈥?/div>
Mask ROM
CXP921064A
鈥?/div>
Piggy/evaluation chip
CXP921000A
Structure
Silicon gate CMOS IC
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E00250A18-PS
