CXP81952M/81960M
CMOS 8-bit Single Chip Microcomputer
Description
The CXP81952M/81960M is a CMOS 8-bit micro-
computer which consists of A/D converter, serial
interface, timer/counter, time base timer, vector
interruption, high precision timing pattern generation
circuit, PWM generator, PWM for tuner, 32kHz
timer/event counter, remote control reception circuit,
and FRC capture unit, as well as basic configurations
like 8-bit CPU, ROM, RAM and I/O port. They are
integrated into a single chip.
Also the CXP81952M/81960M provides sleep/stop
functions which enable to lower power consumption
and ultra-low speed instruction mode in 32kHz
operation.
100 pin QFP (PIastic)
100 pin LQFP (PIastic)
Structure
Silicon gate CMOS IC
Features
鈥?/div>
A wide instruction set (213 instructions) which covers various types of data
鈥?16-bit operation/multiplication and division/Boolean bit operation instructions
鈥?/div>
Minimum instruction cycle
200ns at 20MHz operation (4.5 to 5.5V)
333ns at 12MHz operation (2.7 to 5.5V)
122碌s at 32kHz operation
鈥?/div>
Incorporated ROM capacity
52K bytes (CXP81952M), 60K bytes (CXP81960M)
鈥?/div>
Incorporated RAM capacity
2048 bytes
鈥?/div>
Peripheral functions
鈥?A/D converter
8 bits, 12 channels, successive approximation system
(Conversion time of 16碌s at 20MHz)
鈥?Serial Interface
Incorporated buffer RAM (1 to 32 bytes auto transfer), 1 channel
Incorporated 8-bit and 8-stage FIFO
(1 to 8 bytes auto transfer), 1 channel
鈥?Timer
8-bit timer, 8-bit timer/counter, 19-bit time base timer,
32kHz timer/counter
鈥?High precision timing pattern generator PPG: maximum of 19 pins, 32 stages programmable
RTG: 5 pins, 2 channels
鈥?PWM/DA gate output
PWM: 12 bits, 2 channels (Repetitive frequency of 78kHz at 20MHz)
DA gate pulse output: 13 bits, 4 channels
鈥?FRC capture unit
Incorporated 26-bit and 8-stage FIFO
鈥?PWM output
14 bits, 1 channel
鈥?Remote control reception circuit
8-bit pulse measurement counter with on-chip 6-stage FIFO
鈥?/div>
Interruption
20 factors, 15 vectors, multi-interruption possible
鈥?/div>
Standby mode
Sleep/stop
鈥?/div>
Package
100-pin plastic QFP/LQFP
鈥?/div>
Piggyback/evaluator
CXP81900M
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E95511A69-PS
