CXL5520M/P Datasheet

  • CXL5520M/P

  • CMOS-CCD Baseband 1H Delay Line

  • 9頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXL5520M/P
CMOS-CCD Baseband 1H Delay Line
For the availability of this product, please contact the sales office.
Description
CXL5520 is a CMOS-CCD baseband 1H delay line
designed for TV signal processing.
Features
鈥?/div>
Single 5V power supply
鈥?/div>
Low power consumption
鈥?/div>
Built-in line locked PLL circuit
鈥?/div>
Built-in 2 comb filters
(Addition of delayed and non-delayed output signal.)
鈥?/div>
Built-in peripheral circuits
Absolute Maximum Ratings
(Ta = 25擄C)
鈥?/div>
Supply voltage
鈥?/div>
Operating temperature
鈥?/div>
Storage temperature
V
DD
Topr
Tstg
+6
鈥?0 to +60
鈥?5 to +150
V
擄C
擄C
Input Signal Amplitude
鈥?/div>
鹵 (R-Y) PAL and NTSC Vsig
鈥?/div>
鹵 (B-Y) PAL and NTSC Vsig
鈥?/div>
鹵 (R-Y) SECAM
Vsig
鈥?/div>
鹵 (B-Y) SECAM
Vsig
525 mVp-p (Typ.)
665 mVp-p (Typ.)
1.05 Vp-p (Typ.)
1.33 Vp-p
(Typ.)
CXL5520M
16 pin SOP (Plastic)
CXL5520P
16 pin DIP (Plastic)
鈥?/div>
Allowable power dissipation
P
D
CXL5520M
CXL5520P
400
800
mW
mW
Recommended Operating Condition
(Ta = 25擄C)
Supply voltage
V
DD
5V 鹵 5%
Recommended Clock Condition
(Ta = 25擄C)
鈥?/div>
Top pulse voltage
V
CLK
3 to 7
鈥?/div>
Frequency
鈥?/div>
Input clock waveform
Pin Description
Pin
No.
1
2
3
4
5
6
7
8
Symbol
V
DD
AB
(NC)
(NC)
SAND
VCO IN
(NC)
GND
Description
+5V supply voltage
Autobias output
not connected
not connected
Sandcastle pulse input
VCO input
not connected
Ground
f
CLK
15.625
Sandcastle pulse
Function
鈥?/div>
2 comb filters outputs
(Addition of delayed and non-delayed output signal.)
鈥?/div>
Timing generator and clock driver
鈥?/div>
Line Locked PLL circuit (Sandcastle pulse)
鈥?/div>
Autobias circuit
鈥?/div>
Pulse clamp circuit
鈥?/div>
Sample and hold circuit and output Amp.
Structure
CMOS-CCD
V
kHz
Pin
No.
9
10
11
12
13
14
15
16
Symbol
(NC)
(NC)
Vo (R-Y)
Vo (B-Y)
(NC)
Vi (B-Y)
(NC)
Vi (R-Y)
Description
not connected
not connected
鹵 (R-Y) output signal
鹵 (B-Y) output signal
not connected
鹵 (B-Y) input signal
not connected
鹵 (R-Y) input signal
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E95X04-PS
