CXD2443Q
Timing Generator for LCD Panels
Description
The CXD2443Q is a timing generator for the LCD
panel LCX011 and LCX019 driver. This chip has a
built-in serial interface circuit which allows various
settings to be performed through external control
from a microcomputer, etc.
Features
鈥?/div>
Generates the LCD panel LCX011/LCX019 drive
pulse
鈥?/div>
Supports NTSC/PAL
(PAL supported by scanning line conversion of
video signal to 525H or pulse eliminate.)
鈥?/div>
Supports WIDE mode (when driving the LCX011)
鈥?/div>
Supports HD mode (when driving the LCX011)
鈥?/div>
Supports up/down and/or right/left inversion
鈥?/div>
Supports 3-panel projectors
鈥?/div>
Generates timing signal of external sample-and-
hold circuit
鈥?/div>
Generates line inversion and field inversion signals
鈥?/div>
AC drive of LCD panels during no signal
鈥?/div>
Line double-speed display realized with a built-in
double-speed controller (NTSC/PAL) (4:3 mode only)
(Line memory 碌PD485505: NEC)
Applications
LCD projectors, etc.
Structure
Silicon CMOS IC
Absolute Maximum Ratings
(Ta = 25擄C, V
SS
= 0V)
鈥?/div>
Supply voltage
V
DD
V
SS
鈥?0.5 to +7.0
V
鈥?/div>
Input voltage
V
I
V
SS
鈥?0.5 to V
DD
+ 0.5 V
鈥?/div>
Output voltage
V
O
V
SS
鈥?0.5 to V
DD
+ 0.5 V
鈥?/div>
Operating temperature
Topr
鈥?/div>
Storage temperature Tstg
鈥?0 to +75
鈥?5 to +150
擄C
擄C
100 pin QFP (Plastic)
Recommended Operating Conditions
鈥?/div>
Supply voltage
V
DD
4.5 to 5.5
鈥?/div>
Operating temperature
Topr
鈥?0 to +75
V
擄C
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E96X31-PS
