CXA3225N
All Band TV Tuner IC (VHF-CATV-UHF)
Description
The CXA3225N is a TV tuner monolithic IC which
integrates local oscillator and mixer circuits for VHF
band, local oscillator and mixer circuits for UHF
band, and an IF amplifier onto a single chip. This IC
adopts a 20-pin SSOP package and is suitable for
miniaturizing voltage synthesizer tuner.
Features
鈥?/div>
Low power consumption (5 V, 46 mA typ.)
鈥?/div>
Single 5 V power supply
鈥?/div>
Superior cross modulation
鈥?/div>
Balance-type UHF oscillator with good oscillation
stability (4 pins)
鈥?/div>
IF output can be selected from symmetrical or
asymmetrical
鈥?/div>
Double-tuned filter can be connected to MIX output
鈥?/div>
SSOP 20-pin package
Applications
鈥?/div>
TV tuners
鈥?/div>
VCR tuners
鈥?/div>
CATV tuners
Structure
Bipolar silicon monolithic IC
20 pin SSOP (Plastic)
-Absolute Maximum Ratings
(Ta=25 擄C)
鈥?/div>
Supply voltage
鈥?/div>
Storage temperature
V
CC
1
Tstg
鈥?.3 to +5.5
鈥?5 to +150
V
擄C
鈥?/div>
Allowable power dissipation
P
D
465
mW
(when mounted on a printed circuit board)
Operating Conditions
鈥?/div>
Supply voltage
鈥?/div>
Operating temperature
V
CC
1
Topr
4.75 to 5.30
鈥?0 to +75
V
擄C
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E98950-TE
