CXA3185 Datasheet

  • CXA3185

  • All Band TV Tuner IC with On-chip PLL

  • 23頁

  • SONY   SONY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXA3185/3186N
All Band TV Tuner IC with On-chip PLL
Description
The CXA3185/3186N is a monolithic TV tuner IC
which integrates local oscillator and mixer circuits for
VHF band, local oscillator and mixer circuits for UHF
band, an IF amplifier and a tuning PLL onto a single
chip, enabling further miniaturization of the tuner.
Features
鈥?/div>
Low noise figure
鈥?/div>
Low power consumption (5 V, 54 mA typ.)
鈥?/div>
On-chip tuning PLL (3-wire bus format)
鈥?/div>
Selection of frequency steps 31.25 kHz, 50 kHz
and 62.5 kHz
鈥?/div>
On-chip 4-output band switch
Applications
鈥?/div>
TV tuners
鈥?/div>
VCR tuners
鈥?/div>
CATV tuners
Structure
Bipolar silicon monolithic IC
Absolute Maximum Ratings
(Ta = 25 擄C)
鈥?/div>
Supply voltage
V
CC
1,V
CC
2
鈥?.3 to +5.5
鈥?.3 to +10.0
鈥?5 to +150
V
V
擄C
V
CC
3
鈥?/div>
Storage temperature
Tstg
鈥?/div>
Allowable power dissipation
P
D
30 pin SSOP (Plastic)
880
mW
(when mounted on a substrate)
Operating Conditions
鈥?/div>
Supply voltage V
CC
1, V
CC
2
V
CC
3
鈥?/div>
Operating temperature
Topr
4.75 to 5.3
4.75 to 9.45
鈥?0 to +75
V
V
擄C
Note)
Electrostatic discharge strength is weak, and care should be taken in handling this IC.
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E97944-TE
