CXA3179N Datasheet

  • CXA3179N

  • IF Amplifier for M-ary FSK Pagers (AFC Supported)

  • 27頁

  • SONY   SONY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXA3179N
IF Amplifier for M-ary FSK Pagers (AFC Supported)
Description
The CXA3179N is a low current consumption FM
IF amplifier which employs the newest bipolar
process. It is suitable for M-ary FSK pagers using
AFC.
Features
鈥?/div>
Low current consumption : 1.1 mA
(typ. at V
CC
=1.4 V)
鈥?/div>
Low voltage operation : V
CC
=1.1 to 4.0 V
鈥?/div>
Small package 24-pin SSOP
鈥?/div>
Second mixer and oscillator
鈥?/div>
Needless of IF decoupling capacitor
鈥?/div>
Reference power supply for operational amplifier
and comparator
鈥?/div>
Bit rate filter with variable cut-off
鈥?/div>
AFC current output circuit
鈥?/div>
RSSI function
鈥?/div>
IF input, V
CC
standard
鈥?/div>
Maximum input frequency : 30 MHz
Applications
鈥?/div>
M-ary FSK pagers
鈥?/div>
Double conversion pagers
Structure
Bipolar silicon monolithic IC
Block Diagram and Pin Configuration
REG CONT
REG OUT
NRZ OUT
LVA OUT
AFC C.
AFC OFF
L.C. OUT
MIX IN
AUDIO
RSSI
GND
24 pin SSOP (Plastic)
Absolute Maximum Ratings
鈥?/div>
Supply voltage
V
CC
鈥?/div>
Operating temperature Topr
鈥?/div>
Storage temperature
Tstg
鈥?/div>
Allowable power dissipation
P
D
Operating Condition
Supply voltage
7.0
鈥?0 to +75
鈥?5 to +150
417
V
擄C
擄C
mW
V
CC
1.1 to 4.0
V
24
23
22
21
20
19
18
17
B.S.
16
15
14
13
RSSI
GND
REG
MIX
OSC
IF_LIM
AFC
QUAD_DET
FILTER
LVA
LEVEL
COMP
1
OSC IN
2
OSC OUT
3
MIX OUT
4
V
CC
5
IF IN
6
TH CONT
7
AFC
8
QUAD
9
C1
10
11
12
C2
C3
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
FIL SW
E96Y06A8Z
