CXA2561Q Datasheet

  • CXA2561Q

  • Dolby B-C Type Noise Reduction System with Playback Equalize...

  • 20頁

  • SONY   SONY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXA2561Q
Dolby
鈭?/div>
B-C Type Noise Reduction System with Playback Equalizer Amplifier
Description
The CXA2561Q is an IC designed for use in car
stereo cassette decks. Functions include Dolby B-C
type noise reduction (NR) system, playback equalizer
amplifier and music sensor into a single chip.
Features
鈥?/div>
Few external parts
鈥?/div>
Small package (40-pin QFP)
鈥?/div>
Same pin configuration as for the Dolby B type NR
system (CXA2560Q) and no Dolby NR system
(CXA2559Q)
鈥?/div>
Dolby B-C type NR and playback equalizer
amplifier into a single chip
鈥?/div>
FORWARD/REVERSE head select switch
鈥?/div>
Mute function
鈥?/div>
Music signal interval detection level can be set by
the external resistors/capacitors (2 modes).
鈥?/div>
High-frequency cut-off of the music sensor circuit
can be adjusted by the external capacitance.
Applications
鈥?/div>
Car stereo cassette decks
鈥?/div>
Playback-only cassette decks
Structure
Bipolar silicon monolithic IC
Absolute Maximum Ratings
鈥?/div>
Supply voltage
V
CC
鈥?/div>
Operating temperature Topr
鈥?/div>
Storage temperature Tstg
鈥?/div>
Power dissipation
P
D
Operating Condition
Supply voltage
40 pin QFP (Plastic)
12
鈥?0 to +85
鈥?5 to +150
430
V
擄C
擄C
mW
V
CC
7.8 to 11
V
鈭?/div>
This IC is available only to the licensees of Dolby Laboratories Licensing Corporation from whom licensing and applications
information may be obtained.
鈭?/div>
"Dolby" and the double D symbols are trademarks of Dolby Laboratories Licensing Corporation.
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
