CXA2543R
Decoder/Driver/Timing Generator for Color LCD Panels
Description
The CXA2543R is an IC designed exclusively to
drive the color LCD panel DCX501BK and LCX018AK.
This IC greatly reduces the number of circuits and
parts required to drive LCD panels by incorporating
RGB decoder functions for video signals, driver
functions, and a timing generator for driving panels
onto a single chip.
This chip has a built-in serial interface circuit and
electronic attenuators which allow various mode
settings and adjustments to be performed through
direct control from an external microcomputer, etc.
Features
鈥?/div>
Color LCD panel DCX501BK and LCX018AK driver
鈥?/div>
Supports NTSC and PAL signals
鈥?/div>
Supports 16:9 wide display
鈥?/div>
Supports composite inputs, Y/C inputs and Y/color
difference inputs
鈥?/div>
Serial interface circuit
鈥?/div>
Electronic attenuators (D/A converter)
鈥?/div>
BPF, trap and delay line
鈥?/div>
Sharpness function
鈥?/div>
2-point
緯
correction circuit
鈥?/div>
R, G, B signal delay time adjustment circuit
鈥?/div>
Polarity inversion circuit (line inverted mode)
鈥?/div>
Supports external RGB input
鈥?/div>
Supports AC drive for LCD panel during no signal
Applications
鈥?/div>
Compact LCD monitors
鈥?/div>
LCD viewfinders
鈥?/div>
Compact liquid crystal projectors, etc.
Structure
Bipolar CMOS IC
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Absolute Maximum Ratings
(Ta = 25擄C)
鈥?/div>
Supply voltage
V
CC
1 鈥?GND1 6
V
CC
2 鈥?GND2 14
V
CC
3 鈥?GND3 14
V
DD
1 鈥?V
SS
1
V
DD
1 鈥?V
SS
2
4.5
4.5
V
V
V
V
V
64 pin LQFP (Plastic)
Analog input pin voltage VINA
鈥?.3 to V
CC
V
Digital input pin voltage VIND 鈥?.3 to V
DD
1 + 0.3 V
Operating temperature Topr
鈥?5 to +75 擄C
Storage temperature
Tstg
鈥?0 to +125 擄C
Allowable power dissipation
鈭?/div>
1
P
D
(Ta
鈮?/div>
75擄C) 350 mW
Operating conditions
Supply voltage V
CC
1 鈥?GND1
V
CC
2 鈥?GND2
V
CC
3 鈥?GND3
V
DD
1 鈥?V
SS
1
V
DD
1 鈥?V
SS
2
4.25 to 5.25
11.0 to 13.5
11.0 to 13.5
2.7 to 3.6
2.7 to 3.6
V
V
V
V
V
鈭?/div>
1
With substrate Size: 30
脳
30
脳
1.6mm
Material: Glass fabric base epoxy
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E98403-PS
