CXA2534Q Datasheet

  • CXA2534Q

  • 4-Channel CD Motor Driver

  • 23頁

  • SONY   SONY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXA2534Q
4-Channel CD Motor Driver
Description
CXA2534Q is a 4-channel H-bridge motor driver IC
designed for portable CD systems. It has a built-in
DC to DC converter controller that allows voltage
step-up to typically 3.2 V; this voltage can be used
to power the system DSP, SSP and micro-controller.
In addition, it also provides a PWM regulated power
supply to the H-bridge output stage so as to ensure
high efficiency.
Features
鈥?/div>
4 channels of H-bridge drivers
鈥?/div>
PWM regulated power supply for H-bridge output
stages
鈥?/div>
Step-up DC to DC converter controller for system
power supply
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Start and off controls with soft start capability
Reset pulse
Short circuit protect
Over-voltage protect
Low battery voltage detection
Rechargeable battery charger
General purpose operational amplifier
Thermal shut-down for battery charger and H-
bridge driver (170 擄C/140 擄C)
鈥?/div>
Direct interface with wired remote controller
possible
Applications
Portable CD player
Structure
Bipolar silicon monolithic IC
48 pin QFP (Plastic)
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E99145-TE
