CXA2503 Datasheet

  • CXA2503

  • Decoder/Driver/Timing Generator for Color LCD Panels

  • 72頁

  • SONY   SONY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXA2503AR
Decoder/Driver/Timing Generator for Color LCD Panels
For the availability of this product, please contact the sales office.
Description
The CXA2503AR is an IC designed exclusively to
drive color LCD panels LCX005BK/BKB and
LCX009AK/AKB.
This IC greatly reduces the number of circuits and
parts required to drive LCD panels by incorporating
RGB decoder functions for video signals, driver
functions, and a timing generator for driving panels
onto a single chip.
This chip has a built-in serial interface circuit and
electronic attenuators which allow various mode
settings and adjustments to be performed through
direct control from an external microcomputer, etc.
Features
鈥?/div>
Color LCD panels LCX005BK/BKB and LCX009AK/
AKB driver
鈥?/div>
Supports NTSC and PAL systems
鈥?/div>
Supports 16:9 wide display
鈥?/div>
Supports composite inputs, Y/C inputs and Y/color
difference inputs
鈥?/div>
Serial interface circuit
鈥?/div>
Electronic attenuators (D/A converter)
鈥?/div>
BPF, trap and delay line
鈥?/div>
Sharpness function
鈥?/div>
2-point
緯
correction circuit
鈥?/div>
R, G, B signal delay time adjustment circuit
鈥?/div>
Polarity inversion circuit (line inverted mode)
鈥?/div>
Supports external RGB input
鈥?/div>
Supports AC drive for LCD panel during no signal
Applications
鈥?/div>
LCD viewfinders
鈥?/div>
Compact liquid crystal projectors
鈥?/div>
Compact LCD monitors
Structure
Bipolar CMOS IC
Absolute Maximum Ratings
(Ta = 25擄C)
6
鈥?/div>
Supply voltage V
CC
1 鈥?GND1, 3
V
CC
2 鈥?GND2
14
V
DD
1 鈥?V
SS
1
4.5
V
DD
2 鈥?V
SS
2
鈥?/div>
Analog input pin voltage VINA
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
4.5
鈥?.3 to V
CC
1
64 pin LQFP (Plastic)
V
V
V
V
V
Digital input pin voltage VIND 鈥?.3 to V
DD
1 + 0.3 V
Operating temperature Topr
鈥?5 to +75 擄C
Storage temperature
Tstg
鈥?0 to +125 擄C
Allowable power dissipation
P
D
(Ta
鈮?/div>
75擄C) 350mW
Note)
Operating conditions
Supply voltage V
CC
1 鈥?GND1, 3 4.25 to 5.25
V
CC
2 鈥?GND2
11.0 to 13.5
V
DD
1 鈥?V
SS
1
2.7 to 3.6
V
DD
2 鈥?V
SS
2
2.7 to 3.6
Note)
With substrate
Size: 114.3
脳
76.1
脳
1.5mm
Material: Glass fabric base epoxy
V
V
V
V
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E97910-PS
