CXA2108AQ Datasheet

  • CXA2108AQ

  • Constant-Current Driver for Full Color LED Display

  • 27頁

  • SONY   SONY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXA2108AQ
Constant-Current Driver for Full Color LED Display
Description
The CXA2108AQ is a 1,024-gradation LED driver
which is ideal for full color LED displays. This IC has
24 outputs and a maximum output current of 70mA.
Time division allows driving of either two or six LEDs
per output by connecting an external FET or other
switch. The luminance (PWM) and drive current for
each LED are set using the internal RAM. The LED
type is common anode.
80 pin QFP (Plastic)
Features
鈥?/div>
24 outputs: 10-bit (1,024-gradation) PWM current outputs
鈥?/div>
Maximum output current: 70mA
鈥?/div>
LED type: Common anode
鈥?/div>
4-bit brightness function capable of switching the basic PWM pulse width in 16 steps
鈥?/div>
Time division allows driving of up to six LEDs with a single output, making it possible to configure a high
definition display with few driver ICs.
鈥?/div>
Coarse Adj. (2 bits) and Fine Adj. (8 bits) output current adjustment for each LED makes it possible to drive
R, G and B using the same output from the same IC. In addition, the characteristics variance of each LED
can also be corrected.
鈥?/div>
All luminance (PWM) data and drive current data are set by writing to the internal RAM.
鈥?/div>
PWM emitting can be performed up to 15 times per frame to realize a screen with little flicker.
鈥?/div>
Two built-in PWM data RAM make it possible to set the next luminance data even during PWM operation.
鈥?/div>
Abnormal internal temperature detection circuit
鈥?/div>
Single 5V power supply
鈥?/div>
Current output with protection diode (diode cathode voltage: VPD can be supplied independently of the 5V
power supply.)
鈥?/div>
Surface mounting package (80-pin QFP)
Applications
LED display panels
Structure
Bi-CMOS silicon monolithic IC
Absolute Maximum Ratings
(Ta = 25擄C)
鈥?Supply voltage
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
AV
CC
, DV
CC
VPD
Digital input voltage
V
I
_D
Digital output current
Io_D
Driver output voltage
V_DVR
Driver output current
I_DVR
鈭?/div>
1
Operating temperature
Topr
Storage temperature
Tstg
Allowable power dissipation
鈭?/div>
1
(Ta = 65擄C or less) P
D
AV
CC
, DV
CC
VPD
Vcmp
Ta
Tc
鈥?.3 to +6.0
鈥?.3 to +10.5
鈥?.3 to DV
CC
+ 0.3
鈥?.0 to +5.0
0 to VPD + 0.3
鈥? to +80
鈥?0 to +80
鈥?5 to +150
1.5
4.75 to 5.25
AV
CC
to 10
1.0 to VPD + 0.3
(I_DVR = 0 to 70mA)
鈥?0 to +65
鈥?0 to +110
V
V
V
mA
V
mA
擄C
擄C
W
V
V
V
擄C
擄C
Recommended Operating Range
鈥?Supply voltage
鈥?Driver output compliance voltage
鈥?Operating temperature (ambient temperature)
鈭?/div>
1
鈥?Operating temperature (case temperature)
鈭?/div>
1
鈭?/div>
1
When mounted on a printed circuit board
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E99160-PS
