CXA2096 Datasheet

  • CXA2096

  • Digital CCD Camera Head Amplifier

  • 16頁

  • SONY   SONY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXA2096N
Digital CCD Camera Head Amplifier
Description
The CXA2096N is a bipolar IC developed as a
head amplifier for digital CCD cameras. This IC
provides the following functions: correlated double
sampling, AGC for the CCD signal, A/D sample and
hold, blanking, A/D reference voltage, and an output
driver.
Features
鈥?/div>
High sensitivity made possible by a high-gain AGC
amplifier
鈥?/div>
Blanking function provided for the purpose of
calibrating the CCD output signal black level
鈥?/div>
Regulator output pin provided for A/D converter
reference voltage
鈥?/div>
Built-in sample-and-hold circuits for camera signals
required by external A/D converters
Absolute Maximum Ratings
鈥?/div>
Supply voltage
鈥?/div>
Operating temperature
鈥?/div>
Storage temperature
鈥?/div>
Allowable power dissipation
Operating Conditions
Supply voltage
24 pin SSOP (Plastic)
V
CC
Topr
Tstg
P
D
11
鈥?0 to +75
鈥?5 to +150
417
V
擄C
擄C
mW
V
CC
1, 2, 3 3.0 to 3.6
V
Applications
DVC/still cameras for consumer use
Structure
Bipolar silicon monolithic IC
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E97449B8Y
