CXA1386K Datasheet

  • CXA1386K

  • 8-bit 75MSPS Flash A/D Converter

  • 21頁

  • SONY   SONY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXA1386P/K
8-bit 75MSPS Flash A/D Converter
Description
The CXA1386P/K are 8-bit high-speed flash A/D
converter ICs capable of digitizing analog signals at
the maximum rate of 75MSPS. The digital I/O levels
of these A/D converters are compatible with the
ECL 100K/10KH/10K.
The CXA1386P/K is pin-compatible with the
earlier
models
CXA1056P/K,
CXA1016P/K,
respectively. They can be replaced by the
CXA1386P/K without any design changes, in most
cases. Compared with the earlier models, these
new models have been greatly improved in
performance, by incorporating advanced process,
new circuit design and carefully considered layout.
Features
鈥?/div>
Differential linearity error: 鹵1/2LSB or less
鈥?/div>
Integral linearity error: 鹵1/2LSB or less
鈥?/div>
High-speed operation with maximum conversion
rate of 75MSPS (Min.)
鈥?/div>
Wide analog input bandwidth: 150MHz (Min. for
full-scale input)
鈥?/div>
Low Power consumption: 580mW (Typ.)
鈥?/div>
Single power supply: 鈥?.2V
鈥?/div>
Low input capacitance: 17pF (Typ.)
鈥?/div>
Built-in integral linearity conpensation circuit
鈥?/div>
Low error rate
鈥?/div>
Operable at 50% clock duty cycle
鈥?/div>
Good temperature characteristics
鈥?/div>
Capable of driving 50鈩?loads
Pin Configuration
Pins with name are NC pins (not connected).
LINV
DV
EE
DGND
(LSB) D0
D1
D2
D3
D4
D5
1
2
3
4
5
6
7
8
9
CXA1386P
28 AV
EE
27 V
RT
26 AV
EE
25 AGND
24 V
IN
23 AGND
22 V
RM
21 AGND
20 V
IN
19 AGND
18 AV
EE
17 V
RB
16 CLK
15 CLK
39
AV
EE
40
AV
EE
41
V
RT
42
43
44
AV
EE
1
2
3
LINV
4
DV
EE
5
DGND1
6
DGND2
7
CXA1386P
28 pin DIP (Plastic)
CXA1386K
44 pin LCC (Ceramic)
Structure
Bipolar silicon monolithic IC
Applications
鈥?/div>
Digital oscilloscopes
鈥?/div>
HDTV (high-definition TVs)
鈥?/div>
Other apparatus requiring high-speed A/D
conversion
38 37 36 35 34 33 32 31 30 29
AGND
V
IN
AGND
V
RM
AGND
V
IN
AGND
CXA1386K
D6 10
(MSB) D7 11
DGND 12
DV
EE
13
MINV 14
28
27
26
25
24
23
22
21
20
19
18
AV
EE
AV
EE
V
RB
CLK
CLK
MINV
DV
EE
DGND1
8 9 10 11 12 13 14 15 16 17
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
(LSB) D0
D1
D2
D3
D4
D5
D6
(MSB) D7
DGND2
E90114C54-ST
